Differential rear axle assembly tricycle rear axle

FOB Reference Price:Get Latest Price
$125.00 - $145.00 / Sets | 100 Set/Sets sample is acceptable for tricycle rear axle (Min. Order)
Model Number:
QG-R8
Report Suspicious Activity
Overview
Quick Details
Use For:
Cargo
Driving Type:
Motorized
Body Type:
Closed
Certification:
CCC
Displacement:
> 250cc
Brand Name:
Qiaoguan/OEM
Place of Origin:
Chongqing, China (Mainland)
Size:
1040mm
Brake:
Drum brake
Origin:
China
Real axle factory:
YES
Brand:
Qiaoguan/OEM
Shaft type:
full floating
Ratio:
12:30 / 10:29 / 8:28
Length:
980/1040/1080/1130/1180/other
Axle case:
CNC processing
MOQ:
100pcs
Shipping:
within 3~5days
Supply Ability
Supply Ability:
12000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
indivitual packing
can do as customers required
Port
Chongiqng/Shanghai/Guangzhou

Differential rear axle assembly tricycle rear axle



1.Features

1. Axle case is produced by CNC and special machine.

2. Thicken Semi-axis,

3. Increased Gear Modules

4. Double fixing devices easy to handle

5. Able to produce and sell about 100 thousands rear axle every year.



2. product  specification

Item Name

Full Floating Rear Axle with King Assistor 8th Generation

Speed ratio

12:30 10:29 8:28

Drum distance

980 / 1040 / 1080 / 1130 / 1180

Differential Mechanism

Full Floating 3 SpeedsDifferential 8th generation

Full Floating Type

Connection plate :

5 holes,

φ110mm S.A.

φ140mm reference circle

wheel bolt M14*1.5-50



Semi Axis:

Involute spline Z=23

Semi Floating Type

Connection plate :

4 holes,

φ57 mm S.A.

φ114 mm reference circle

wheel bolt M12*1.25-39



Semi Axis:

Rectangular Spline 6-25*21*5

Certification

CCC  CE  ISO
Connection type

Rectangular Spline 6-20*17*4

Braking type

Mechanical brake φ220 / φ240

oil brake φ220



3.Product Picture







4. Our Patent About the Rear Axle & the Differential







5. Product  Line





6. Packaging & Shipping







7. More Products:



 8. FAQ

 1. Q: Can I have a sample

 A: Yes we accept  for trail order



 2: Q: Whats your delivery time

 A: It usualy take 3~4 days to finish production, for container order, one week.



 3.Q: What speed ratio of this rear axle?

 A:  we can customize as you need, normall option is as 12:38, 13:37, 10:29,8:28, etc



4. Q: Can I use my logo on the product

A: Yes, we can make the customers’ logo.



5.Q: How to delivery  to foreign buyer



A: For full container order, usually by sea.
