Digicast Support H.265/H.264 Main Profile/High Profile And MP3 & AAC Audio Compression H264 Encoder Video IP Encoder Decoder

Feedback Ratings
  • 1 Pieces
    $169.00
  • 2-9 Pieces
    $149.00
  • >=10 Pieces
    $139.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces)
software (Min. Order: 1 Pieces)
hardware (Min. Order: 1 Pieces) Less
Contact Supplier
Samples - $169.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
DIGICAST
Model Number:
DMB-8900A-EC(HD MI IN)
Nature:
IPTV Live Streaming H.265 IPTV Encoder
Video Inputs:
one channel HD MI/SDI for option
Output:
4 groups TS over IP stream out
IP Protocol ouput:
RTMP/RTSP/HTTP/UDP/HLS
Video Encoding:
H.265/H.264 Main Profile/High Profile and MP3 & AAC audio compression
Audio Encoding:
AAC, MP3
Resolution:
Up to 1080P Full HD
Bitrate:
VBR/CBR
Configuration Interface::
Web operation
Bitrate mode:
CBR/VBR 16Kbit/s~12Mbit/s

Packaging & Delivery

Selling Units:
Single item
Single package size:
22.5X16.5X6.5 cm
Single gross weight:
0.6 kg
Package Type:
Digicast Support H.265/H.264 Main Profile/High Profile And MP3 & AAC Audio Compression H264 Encoder Video IP Encoder Decoder Packaging size: 22.5*16.5*6.5, weight: 0.6kg Fast shipping via international express delivery. Orders can be delivered within 3-5 days. Convenient!
Lead Time :
Quantity(Piece) 1 - 1 >1
Est. Time(days) 3 To be negotiated
Video Description
Contact us
Contact Person
Bruce Chen
E-mail
service@ digicast.cn
Company Website
www.digicast.cn
Whatsapp/Wechat Phone
+86-17888214818
Skype
17888214818
NEW PRODUCTS

DMB-8800A Premium2

ProVideo Streaming Encoder

Input: 1*HD MI+*2CVBS

Output: TS over IP(1000M)

DMB-8804AS Classic ProVideo Streaming Encoder

Input: 4*CVBS

Output: TS over IP(1000M)


DMB-8900B ProVideo Streaming Decoder

Input: IP(HLS/HTTP/RTSP/UDP/RTMP)

Output: 1*HD MI/CVBS+3.5mm

DMB-8804A-EC Classic  Mini Portable Economic Encoder

Input: 4*HD MI+2*3.5mm in

Output: TS over IP(1000M),Up to 1080P60fps

DMB-8808A-EC Classic ProVideo Streaming Encoder

Input: 8-Channel HD MI IN
Output: IP Streaming output

DMB-8804 Premium2 ProVideo Streaming Encoder

Input: 4*HDMI and 8*CVBS (A/V) IN

Output: TS over IP stream out.

DMB-8808S Classic ProVideo Streaming Encoder

Input: 8*CVBS
IP Output: TS over IP(1000M)

DMB-8816 Premium2 ProVideo Streaming Encoder

Input: 16 *HDMI+32 *CVBS
IP Output: TS over IP stream out

DMB-9160A IP/TS Multiplexer


Input: 8*ASI MPTS/SPTS
IP Output: Capable Of Scrambling

DMB-8800A-EC Family
Order Guide: MINI Series - Economic Streaming Encoder                  ● → Yes   - → No

     Model
Configuration
DMB-8800A-EC
Classic
DMB-8800A-EC
Classic
DMB-8900A-EC
Classic
DMB-8804A-EC
Classic
DMB-8808A-EC
Classic
Video Input
 HDMI
SDI
HDMI/SDI
(1 of 2)
4*HDMI
8*HDMI
Audio Input
Embedded & Jack in
Embedded
Embedded
Embedded & 2*Jack in
Embedded
Output
IP Streaming
IP Streaming
IP Streaming
IP Streaming
IP Streaming
H.264/AVC
H.265/HEVC
-
-
-
-
Dolby AC3
1080P 30fps

1080P 60fps
-
Preview
Web&APK
Control
OSD
Subtitle
Product Description

OVERVIEW

In a fast changing and highly competitive TV market, operators and TV service providers must deliver access to content on all screens, anytime, anywhere, while also reducing complexity and driving efficiency across all platforms.

DMB-8900A-EC Classic H.265/HEVC IPTV Streaming Encoder features high performance, low latency and low bit rates for IPTV/OTT systems, realized Video & Audio real-time transmission via internet, and adopts state-of-the-art compression technology of H.265/HEVC, which realizes its resolution to be up to 1080P/60fps. With powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate which can efficiently save the cost of bandwidth. DMB-8900A-EC Classic accepts 1*HDMI input, then output 4 groups TS over IP in H.265 format with multi-protocol, multi-resolution which can be freely adjusted according to your needs.

DMB-8900A-EC Classic provides fully functional second development package, which can be applied to education, health care, IPTV, conference, remote education, news interview, court, public security, banking, transportation and other industry application.

FEATURES

* Video Input: one channel HDMI/SDI for option
* Video compression up to Full HD 1080P@60fps
* Support up to 4 groups TS over IP stream out
* Support H.265/H.264 Main Profile/High Profile and MP3 & AAC audio compression
* Bitrate mode: CBR/VBR 16Kbit/s~12Mbit/s
* Support streaming resolution settings
* GOP frame rate settings supported
* Capable of image parameter settings
* Insertable of logo and Scroll Caption; Adjustable of audio gain
* Video Output: Multiple output streams per input service to support Broadcast, VOD, IPTV and OTT, Mobile/ web, Set top box applications
* Switchable of audio output mode: Left, right and Stereo

* Configurable of Multi-bitrate, Multi-resolution, Multi-protocol

* Providing HLS, RTSP, HTTP, UDP and RTMP protocol
* Compatible with HDCP, ONVIF Network Video Protocol

* Any IOS browsers (iphone, ipad, MacBook etc) are able to have streams from IPTV Streaming Encoder in Anytime, Anywhere by HLS protocol without install any software players.
*Any terminal devices/decoders are able to have streams from IPTV Streaming Encoder directly by RTMP protocol with software players(such as VLC).

* System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX
*Support Microsoft standard flow driven architecture (WDM architecture), support Microsoft WMENCODER, compatible with Windows VFW software architecture and WDM mode.
* Web-based management
* Full-duplex mode 1000M

Specification
Specification










VIDEO Encoding
Video compression:H.265 HEVC, H.264/AVC High Profile Level 4.0
Video inputs: HDMI(HDCP supported) or SDI for option
Analog video input mode: PAL, NTSC
Resolution:
Main stream:
1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540,720x480,
720x404,704x576,640x480,640x360,auto
Sub-stream:
1280x720,800X450,720x576,720x540,720x480,720x404,704x576,640x480,
640x300,352X288,320X240,320X180 auto
Third-stream:
720x576,720x540,720x480,720x404,704x576,640x480,
640x300,352X288,320X240,320X180 auto
Forth-stream:
720x576,720x540,720x480,720x404,704x576,640x480,
640x300,352X288,320X240,320X180 auto
Bit-rate: 16kbps~12Mbps, CBR/VBR
Video pre-processing: Noise reduction, Sharpen, Filtering




AUDIO Encoding
* Audio compression: AAC,AAC+,AAC++,MP3,MP2
* Audio input: Full HD embedded + 3.5mm
* Sampling accuracy: 24-bit
* Bit Rate: 48kbps~320kbps
* Sample-rate: 44.1KHz, 48KHz



IP Streaming output
* Transport protocol: TS over IP output, HLS, RTSP, HTTP, UDP and RTMP protocol
* For each Full HD to IP output, supporting output 4 groups TS over IP streams (for each group the HLS, HTTP, RTSP, UDP and RTMP protocol all enabled). with 4 different resolutions (up to 1080p) and 4 different bitrates to meet different size screen and different bandwidth condition.
* Connector: RJ45, 1000M


Physical And Power
* Voltage: 12V
* Consumption: less than 5W
* Operating temperature: 0~45℃(operation), -20~65℃(storage)
* Dimensions: 112mm(W)*100mm(D)*28mm(H)
* Net Weight: 0.3 KG
