Distance education and training H.264 Multiple interfaces iptv streaming server hd mi video encoder

FOB Reference Price:Get Latest Price
$440.00 - $500.00 / Piece | 1 Piece/Pieces (Min. Order)
Samples:
$900.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Lead Time:
Quantity(Pieces) 1 - 10 >10
Est. Time(days) 3 Negotiable
Customization:
Customized logo (Min. Order: 50 Pieces)
Report Suspicious Activity
Overview
Quick Details
Certification:
FCC
Place of Origin:
Beijing, China
Brand Name:
TCHD
Model Number:
6C0
Product name:
H.264 Multiple interfaces iptv streaming server encoder
Input:
HD MI/SDI/VGA/YPbPr/S-video/CVBS
Output:
RTMP/RTSP/UDP/HTTP/TCP
Resolution:
1920x1080P60
Audio:
Independent audio
Feature:
Ethernet streaming
Application:
Live streaming, webcasting,distance education and training
Model:
6C0
Max. FPS:
60/50fps @ 1920x1080p
Recording Mode:
Hardware Compression, Real-Time Mode
Supply Ability
Supply Ability:
300 Piece/Pieces per Month Video encoder
Packaging & Delivery
Packaging Details
Carton box
Port
Beijing
Lead Time :
Quantity(Pieces) 1 - 10 >10
Est. Time(days) 3 To be negotiated

Distance education and training H.264 Multiple interfaces iptv streaming server hd mi video encoder

Details

Introduction

TC-6C0 live streaming video encorder is a professional audio and video encoding product, which
supports HDMI/DVI/VGA/AV/Component/CVBS/Left and Right audio channels inputs,compatible with different audio and video signal output devices, H.264 encoding. The code rate is adjustable, and the picture quality can be controlled. This device has only 1 Frame Delay,which ensures the Live streaming frequently.
It is easy to install, plug&play, and there is no computer hardware compatibility issues.Support HTTP/RTSP/RTMP/TCP/UDP streaming.

6C0 Product Series Hardware Specification

Model

6C0

Max. FPS

60/50fps @ 1920x1080p

Recording Mode

Hardware Compression, Real-Time Mode

Input Interfaces

Video

1 x BNC for 3G / HD / SD-SDI

3 x BNC for YPbPr /CVBS/S-Video

1 x DVI-I for DVI-D /HDMI and DVI-A/ VGA

1 x HDMI

Audio

1xStereo audio through

1x RCA for Analog L/R audio

SDI/HDMI/DVI-D embedded audio

1 x 3.5 mm phone jack



Video Feature

H.264/AVC ,  Main / High Profile

Configurable bit rate up to 10Mbps

Supported Resolutions

Input:

1920x1080(P60/P50/P30/P25/P24/i60/i50),1280x720(P60/P50), 1280x1024(P60),1280x960(P60),1024x768(P60),800x600(P60),

720x480(P60/i60),640x480(P60),720x576(P50/i50)

Output:

Resize Range from 128x128 to 1920x1080

*Output Include Down Scaling.

Audio Feature

AAC-LC

Configurable bit rate range from 32Kbps to 384Kbps

Sample rate : 48KHz, 16bit

Network Feature

1x RJ45 for 100/1000Mbps Ethernet

DHCP client

Supported Streaming Protocol

TS over TCP/UDP (unicast & multicast)

RTSP over HTTP/TCP (RTSP Elementary Stream)

RTMP(Publish)

Misc. Features

1 Frame Delay

Dynamic Parameter setting

RS-485

1x USB 2.0 Host for USB storage

Web UI for system configuration

Firmware upgradable

LED indicator

Status With Power Recycle

Record Format

TS

System Requirement

Power Supply

DC 12V (With DC Adapter)
