Double Disc Blade Waste PP PE PVC Grinder Plastic Pulverizer Machine

  • 1 - 5 Sets
    $9,000.00
  • >=6 Sets
    $8,900.00
Model Number:
WR Pulverizer Machine for Plastic
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Jiangsu, China
Plastic Type:
PP/PE/PET/PVC/HDPE/ABS/EVA
Production Capacity (kg/h):
500
Brand Name:
Wanrooe
Use:
Waste Plastic Crusher
Voltage:
380V
Dimension(L*W*H):
2400 x 1800 x4600
Power (kW):
45
Weight (T):
3
Certification:
CE
Warranty:
1 Year, 1year
After-sales Service Provided:
Video technical support, Online support
Applicable Industries:
Manufacturing Plant
Key Selling Points:
High-accuracy
Suitable used for:
PVC PP PET
Disc diameter:
300-500mm
Motor power:
45-110kw
Motor brand:
Siemens
Cooling method:
water cooling
Certificate:
CE
Power source:
380V/50Hz
Capacity:
100-1000kg/h
Power:
45KW
Shaft Design:
Single
Supply Ability
Supply Ability:
500 Set/Sets per Year Double Disc Blade Waste PP PE PVC Grinder Plastic Pulverizer Mac
Packaging & Delivery
Packaging Details
film wrapping and wooden case for Double Disc Blade Waste PP PE PVC Grinder Plastic Pulverizer Machine
Port
shanghai
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 To be negotiated
Video Description

New Design Vertical Double Disc Blade PVC Grinder Waste PP PE Pulverizer Machine for Plastic

Product Description

In order to better give you professional answers, when sending the inquiry, please describe your parameters or technical requirements (such as: processing materials, output size, capacity, etc.) and attach your contact information (such as phone number, e-mail, facebook, whatsapp, wechat, etc.)



Description:

The WANROOETECH’s new design WR series pulverizing system which are introduced from US technology has its compact design, is the perfect fit for the large production user, it use dual grinding disc, one disc as primary disc, another are used for fines grinding disc to improve the capacity. This unit, with its integrated PLC controls, assures the highest quality performance with friendly Human Machine Interface. Up to Double the production rate of similar size conventional water-cooled pulverizing systems, Lower operating costs through 50% energy savings, Lower-maintenance cost-and reduced transportation costs, extended disc life, Optimal finished material quality.



Advantage:

1.Two Grinding disc, one as primary, another used for fines grinding disc, Greater Output than Comparable Models

2.Bigger vibrating screen, up to about: 5M2, make the grinded material get out of the machine as soon as possible, at the same time, cooling grinded material much better

3.Simple adjustment of cutting gap

4. Low drive power - High throughput

5. Innovative efficient design

6. Easy temperature control;

7. HMI Touchscreen with PLC controlling system (Optional)

8. Small Footprint



Optional Components:

Technical Data

WR-300D

WR-400D

WR-500D

Material



LLDPE,LDPE,HDPE,PP,PET...1),PVC...3)

Feed Size

(mm)

3~8

Final Fineness

Mesh (mm)

25~30

Output (kg/h)...2)

30~400

400~800

500~1000

Discs

Number/Diameter (mm)

2/300mm

2/400mm

2/500mm

Main Drive (kw)

45

75

110

Screen Fineness

Number/Area (m²)

4/2.5m²

5/3.2m²

6/4.8m²

Mesh

25~30

Controls



siemens plc controlling system include

Dimensions

L x W x  H (m)

2.4 x 1.8 x4.6

1) further materials upon request .         2) Based on  LLDPE 25~30 Mesh.

3) Rigid PVC(kg/h) : 400~600 for WR-300D;600~1000 for WR-400D;800~1600 for WR-500D.
