Dual stage 1310nm/1480nm/1550nm polarization maintaining PM optical isolator

FOB Reference Price:Get Latest Price
US $1-25 / Pieces | 1 Piece/Pieces optical circulator (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
OEM
Model Number:
PMIS-1111
Product name:
PM fiber optical isolator
Center wavelength:
1310nm/1480nm/1550nm
Operating Wavelength Range:
±20nm
Fiber Type:
SM Panda fiber
dB 50/50 Max.Optical Power(CW):
500mW
Operating Temperature:
-5~+70℃
Storage Temperature:
-40~+85℃
Supply Ability
Supply Ability:
999 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton
20cm*18cm*8cm
Port
shenzhen
Lead Time :
shipped 5-10days after payment
Product Description

Dual stage 1310nm/1480nm/1550nm polarization maintaining PM optical isolator



Features:

Low Insertion Loss

High Return Loss

High Isolation

High Extinction Ratio

High Reliability& Stability



Application:

Communication Systems

Test Instrumentations

Fiber Sensor

Research



Fiber parameters

ParametersValuesUnit
StageSingle Dual-
GradePAPA-

Operation Wavelength

1310nm/1480nm/1550nm nm

Operating wavelength range

±20

nm

Typ. Peak Isolation

42

40

58

55

dB

Min.Isolation at 23℃

28264845

dB

Typ. Insertion Loss at 23℃

0.40.50.50.6

dB

Max. Insertion Loss at 23℃

0.550.650.650.8

dB

Min.Return Loss (input/output)

50/50 dB

Min.Extinction Ratio(only for B type)

20182018dB

Min.Extinction Ratio(only for F type)

25232523dB

Max.Optical Power(CW)

500 mW
Max.Tensile Load5 N
Fiber TypePM Panda Fiber -



Packaging & Shipping



Packaging

Original Carton Package.

As customers' requirement.

Shipping

5-10 Working days after receive the payment.
Shipment: Air transportation ( DHL / UPS / TNT / Fedex / EMS/CHINA POST )

Shipping fee depends on the weight and size.

Company Information



Shenzhen Box Optronics Technology Co., Ltd. is a high-tech enterprises, specialized engaged high power fiber cable, optical communication and optical active device integration technology research and development, production and sales. The company’s idea is quality first, speed first, service first.


Box optronics possesses accountable and dependable service as well as quality products with compact design, high reliability, excellent performance. The products are widely used for scientific research, equipment manufacturing, biomedical experiment, precision measurement, radar communication, material processing, process control, online detection, investigation equipment, national defense, military and other fields.



Workshops



FAQ



 Payment

For large orders, T/T ,

For small orders, Paupal are accepted.



Warranty:

All products have been tested before shipping out

All products have 1 years warranty. ( After the quality guarantee period began to charge appropriate maintenance service fee.)



Refund & Replacement:

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items).

If the items you purchase from our store are not of perfected quality, that is they don't work electronically to manufacturers specifications, simply return them to us for replacement or refund.

If the items are defective, please notify us within 3 days of delivery.

Any items must be returned in their original condition to qualify for a refund or replacement.

The buyer is responsible for all the shipping cost incurred



Contact Us





www.boxoptronics.com

Skype:Box Optronics

Phone: +86 18565771448
