ESP8266 Wifi Wireless Module Serial Port ESP With CE FCC

  • 10-199 Pieces
    $2.00
  • 200-1499 Pieces
    $1.80
  • >=1500 Pieces
    $1.50
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Model Number:
ESP8266
Brand Name:
Original
Place of Origin:
Guangdong, China
Frequency range:
2.4GHz-2.5GHz (2400M-2483.5M)
working current:
80mA
wireless internet mode:
Station/SoftAP/SoftAP+station
SPI FLASH:
512K,1M,2M,4M(can be customize)
module size:
14.3mm*24.8mm*3mm
wireless protocol:
IEEE802.11 b/g/n protocol
data interface:
UART/HSPI/I2C/I2S/Ir Remote Contorl/GPIO/PWM
safety mode:
WPA/WPA2

Packaging & Delivery

Selling Units:
Single item
Single package size:
6X5X3 cm
Single gross weight:
0.2 kg
Package Type:
New and Original, factory sealed packing, it will be pack in one of these packing type: Tube, Tray, Tape and Reel, Tape and Box, Bulk packing, Bag and etc. Please kindly contact us for more details.
Lead Time :
Quantity(Piece) 1 - 1000 >1000
Est. Time(days) 7 To be negotiated

- The smallest 802.11b/g/n Wi-Fi SOC module
- Low power 32-bit CPU, can also serve as the
application processor
- Up to 160MHz clock speed
- Supports UART/GPIO
- DIP-8 package for easy welding
- Integrated Wi-Fi MAC/BB/RF/PA/LNA
- Deep sleep current as low as 20uA
- Embedded lwIP protocol stack
- Supports STA/AP/STA + AP operation mode
- Support Smart Config/AirKiss technology

- UART baudrate up to 4Mbps
- General AT commands can be used quickly
- Supports remote firmware upgrade (FOTA)

Module ModelESP-01
PackageDIP-8
Size14.3mm*24.8mm*3mm
SPI Flash512K,1M,2M,4M(can be customize)
InterfaceUART/GPIO
IO Port2
UART BaudrateSupport 300 ~ 4608000 bps ,Default 115200 bps
Frequency Range2412 ~ 2484MHz
AntennaPCB antenna, 2 dBi
Secondary DevelopmentSupport
Transmit Power802.11b: 16±2 dBm (@11Mbps)
802.11g: 14±2 dBm (@54Mbps)
802.11n: 13±2 dBm (@HT20, MCS7)
Receiving SensitivityCCK, 1 Mbps : -90dBm
CCK, 11 Mbps: -85dBm
6 Mbps (1/2 BPSK): -88dBm
54 Mbps (3/4 64-QAM): -70dBm
HT20, MCS7 (65 Mbps, 72.2 Mbps): -67dBm
Power (Typical Values)Continuous Transmission => Average: ~ 71mA, Peak: 300mA
Modem Sleep: ~20mA
Light Sleep: ~2mA
Deep Sleep: ~0.02mA
SecurityWEP/WPA-PSK/WPA2-PSK
Power SupplyVoltage 3.0V ~ 3.6V,Current >300mA
Operating Temperature-20 c ~ 85 c
Storage Environment-40 c ~ 90 c , < 90%RH
Weight0.65g


Q1:What service do you have?

We provide turnkey solution including RD, PCB fabrication, SMT, testing and other value-added service.



Q2:What are the main products of your PCB/PCBA services?

Our PCB / PCBA services are mainly for the industries including Medical, Automotive, Energy, Metering / Measurements, Consumer Electronics.



Q3:Can we inspect quality during production?

Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house.



Q4:How can we ensure our information should not let third party to see our design?

We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.



Q5:What files required to get quotation from you?

For PCB quotation, please provide the Gerber data / files and indication of related technical requirements as well as any special requirement if you have.

For PCBA quotation, please provide Gerber data / files and also BOM (bill of materials), and if you need us to do function test, please also provide the test instruction/procedure.



Q6:What is standard delivery term?

Delivery terms of EXW, FCA, FOB, DDU etc. are all available based on each quote.



Q7:How long does it take for PCB quote?

Normally 12 hours to 48 hours as soon as receive internal engineer evaluate confirmation.



Q8:Do you have any minimum order quantity (MOQ) requirement?

No, we do not have MOQ requirement, we can support your projects starting from prototypes to mass productions.
