ErP2018 home design smoke artificial ventilation for passive house

  • >=2 Sets
Lead Time:
Quantity(Sets) 1 - 30 >30
Est. Time(days) 25 Negotiable
Customized logo (Min. Order: 30 Sets)
Customized packaging (Min. Order: 30 Sets)
$643.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Quick Details
Place of Origin:
Beijing, China
Brand Name:
Model Number:
Product name:
heat exchanger:
crossflow heat exchanger
10 speeds control
F9, PM2.5 purification
filter alarm:
timer alarm or different pressure gauge alarm available
up to 80%
residential and commercial
Supply Ability
Supply Ability:
8000 Unit/Units per Month
Packaging & Delivery
Packaging Details
Lead Time :
Quantity(Sets) 1 - 30 >30
Est. Time(days) 25 To be negotiated


Product Description

home design smoke artificial ventilation for passive house

 Energy recovery ventilation (ERV) is the energy recovery process of exchanging the energy contained in normally exhausted building or space air and using it to treat (precondition) the incoming outdoor ventilation air in residential and commercial HVAC systems. During the warmer seasons, the system pre-cools and dehumidifies while humidifying and pre-heating in the cooler seasons. The benefit of using energy recovery is the ability to meet the ASHRAE ventilation & energy standards, while improving indoor air quality and reducing total HVAC equipment capacity.




New Eco-Smart HEPA Energy Recovery Ventilator is ERP 2018 compliant.

It is built in energy saving BLDC motor, F9 filter, high efficiency enthalpy heat exchanger. Ideal ventilation solution for residential and light commercial project.


Fresh Fresh air + Energy recovery, reducing running cost of cooling or heating system


Energy efficiency class of A according to regulation EU.No.1254/2014.

1)Energy saving BLDC motor, 10 speeds control
2)High eficiency enthalpy heat recovery, more comfortable indoor climate
3) G3+F9 filter, eficiency over 96% to filter the particulate from 2.5µm to 10µm
4) Intelligent control system, optional CO 2 and humidity control function, external control and BMS control available
5)Double filter alarm, timer alarm or diferent pressure gauge alarm available
6) Auto bypass, intelligent controlled by outdoor temperature
Selection Guide

1. Choose the proper installation types based on the building structure

2. Determine the fresh airflow required according to the use, size and number of persons

3. Select the right specifications and quantity according to the determined fresh airflow





The area of a computer room is 60 sq. meters (S=60), the net height is 3 meters (H=3), and there are 10 per-sons (N=10) in it.

If it is calculated according to “Personal fresh air consumption”, and assume that: Q=70, the result is

Q1 =N*Q=10*70=700(m3/h)

If it is calculated according to “Air changes per hour”, and assume that: P=5, the result is

Q2 =P*S*H=5*60*3=900(m3)

Since Q2 > Q1 , Q2 is better for selecting the unit.


As to special industry such as hospitals (surgery and the special nursing rooms), labs, workshops, airflow re-quired should be determined in conformity with regulations concerned.


ModelRated Air Flow (m3/h)Rated E.S.P (Pa)Enthaply efficiency %TemperatureNoise dB(A)Voltage (V)Power Input (W)Weight (kg)
XHBQ-D1.5DMTHA1507060 ~ 6563 ~ 7075 ~ 8031.5220 ~ 2402425
XHBQ-D2.5DMTHA2509062 ~ 7165 ~ 7373 ~ 8134.5220 ~ 2405627
XHBQ-D3.5DMTHA35014062 ~ 7065 ~ 7374 ~ 8237.5220 ~ 2406533
XHBQ-D5DMTHA50011063 ~ 7267 ~ 7576 ~ 8439220 ~ 2407638
XHBQ-D6.5DMTHA65010060 ~ 6765 ~ 7174 ~ 8241220 ~ 24015362
XHBQ-D8DMTHA80014063 ~ 7165 ~ 7376 ~ 8242220 ~ 24019272
XHBQ-D10DMTHA100014060 ~ 6862 ~ 7276 ~ 8243220 ~ 24024581
XHBQ-D13DMTHA130013558 ~ 7159 ~ 7574 ~ 8243220 ~ 24031581
XHBQ-D15DMTHA15009563 ~ 7165 ~ 7376 ~ 8050220 ~ 240384147
XHBQ-D20DMTHA200011560 ~ 6862 ~ 7276 ~ 8251.5220 ~ 240490167




Company Information

Holtop Factory

Holtop is one of the best manufacturer in ERV/HRV, heat exchanger and AHU area in China, founded in 2002, areas covered more than 30,000 square meters, turnover of 2012 is 42 million dollars, we have enthalpy testing lab. for products test. As a leader in energy/heat recovery equipments, we cooperate with more than 30 famous companies who located in Europe, the Middle east, Korea, Southeast Asia, Taiwan, etc. supplied equipment to Beijing Olympic and Shanghai Expo 2010, works together with domestic and international brands like Midea, Haier, Hitachi, etc.

Holtop partner

Holtop cooperate with world famous brand or offer OEM service including Hitachi, LG, McQuay, TRANE, Systemair, Aldes, York, Haier, Gree, MHI Group, Midea, Carrier, Dunham-Bush, etc.

Holtop products stand for TOP quality in heat recovery ventilation filed in China, certificated by CE, Eurovent, ISO and other different approved tests like anti-flaming test, anti-mold test, energy saving product test. Etc.
