Etching process sensor coded / encoder disc

FOB Reference Price:Get Latest Price
  • 500 - 999 Boxes
    $1.68
  • 1000 - 4999 Boxes
    $1.50
  • 5000 - 9999 Boxes
    $1.10
  • >=10000 Boxes
    $0.76
Report Suspicious Activity
Overview
Quick Details
CNC Machining or Not:
Not CNC Machining
Type:
Etching / Chemical Machining, Laser Machining, Milling, Rapid Prototyping
Material Capabilities:
Brass, Bronze, Copper, Hardened Metals, Precious Metals, Stainless Steel, Steel Alloys
Micro Machining or Not:
Micro Machining
Place of Origin:
Guangdong, China (Mainland)
Model Number:
XHS
Brand Name:
XHS02
Product name:
Etching process sensor coded / encoder disc
thickness:
0.05mm
material:
sus304
Name:
encoder disk
Process:
Punching
Service:
Customized OEM
Usage:
Ray Sensor
Output:
Digital Sensor
Precision metal parts:
photo chemical
Theory:
Optical Sensor
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week Etching process sensor coded / encoder disc
Packaging & Delivery
Packaging Details
Etching process sensor coded / encoder disc
1.first layer using paper bag
2.Second layer is PE bag
3.Foam in the packing bag
4.Wooden box outside
Port
shenzhen
Lead Time :
Shipped in 10 days after payment

Etching process sensor coded / encoder disc

Product Description

Etching process sensor coded / encoder disc

metal encoder  disk

1.SUS304 planarity sheet for photo etching is used.
2.Minimum bar code width is around 0.1mm(t=0.05 mm)
3.Bar pitch tolerance within ±0.02 mm, max and min difference of bar code tolerance in the same lot within 0.02.
4.Center run-out within 0.01, circularity within 0.01 is possible.
5.Internal dia. accuracy range is within 0.03 (0.01 is possible when finished with a reamer.)
6.Technology highlights: Standard processing
7.SUS304 planarity sheet for photo etching is used.
8.Minimum bar code width is around 0.08(t=0.05)
9.Bar pitch tolerance within ±0.003, max and min difference of bar code tolerance in the same lot within 0.04.
10.Center run-out within 0.015, circularity within 0.015 is possible.
11.Internal dia. accuracy range is within 0.04 (0.01 is possible when finished with a reamer.)
