Excavator Used Hydraulic Round Concrete Pile Head Cutter for Breaking 600-1800mm Diameter

$2,000.00 / Piece | 1 Piece (Min. Order)
Model Number:
LYD-HB LYD-HB
Compatible Brand:
ZOOMLION
$2,000.00
- +
available
Kubota
$2,000.00
- +
available
Herrenknecht
$2,000.00
- +
available
All 31 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
LYD
Warranty:
1 Year
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Engineers available to service machinery overseas, Free spare parts
Name:
Pile Head Cutter
Application:
Construction Site
Pile Diameter Range:
600-2500mm
Single Weight:
278KG
Single Module Size:
885x780x340mm
Machinery Tonnage:
≥20t
Material:
45# steel

Packaging & Delivery

Selling Units:
Single item
Single package size:
90X78X34 cm
Single gross weight:
330.0 kg
Package Type:
Wooden box
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description

Excavator Used Hydraulic Round Concrete Pile Head Cutter for Breaking 600-1800mm Diameter

Hydraulic pile breaker can break such like cast-in-place piles, precast piles etc. It can be divided into round and square by the pile shape. Our hydraulic pile breaker is widely used in high-speed railway bridges and civil building pile foundation engineering. Normally hydraulic round pile breaker can break pile diameter from 600-2500mm and hydraulic square pile breaker is suitable for square piles from 300-650mm. Our machine can meet the requirements of all kinds of large-scale infrastructure construction.

Hydraulic Pile Cutter Working principle

Hydraulic pile breaker offer its several cylinders oil pressure through power source and cylinder directly drive the chisels and squeeze the pile body at the same time to break the pile. It operates easily and has high effiency, low noise, low cost in the pile cutting construction process, which is suitable for pile group in construction engineering. Hydraulic pile breaker machine adopts highly modular combinations and connect modules through axis pins. It can break piles in certain ranges

of diameter by different number of modules combination.

Hydraulic Pile Cutter Performance Parameter

Module Number 489101112131415161718

Combination

total weight

kg

Remark Need

 to add the

connections 1600

26242952328036083936426445924920524855765904
Pile diameter rangemm200-800600-800800-10001000-11501150-13001300-15001500-16501650-18001460-19701620-22002200-23602360-2500
Hydraulic excavatorT20-30T30-40THydraulic system/pump station
Max Thrust300KNMax Cylinder required20L/minMachinery Tonnage≥20t
Max Cylinder Trip300mmChisel diameter110mmSingle module weight328kg

Max Cylinder

Pressure

30MPaMax Hoist Capacity≤500mmSingle module size885*780*340mm

Product Description





Hydraulic Pile Cutter Advantages

1.It is the most advanced pile breaker and can achieve high efficiency, low noise in pile broken.

2.It has the advanced modularization and break different diameter pile by different number of modular combination.
3.It has high cost performance, low operating cost and its cost performance is nearly the same with the foreign products.
4.It operates easily and don’t need any professional skill, besides, it operates very safely.
5.It can be connected to a variety of engineering machinery to make achieve of products’ commonality and economical efficiency.

6. It also can be hanged in the excavators, cranes and telescopic arm, etc.High life design can bring you the best benefits



Please ciick products below to see more details

Main products

Trade show



Company Information

Lydite is a professional high tech enterprise based in Wu xi with an area of 5000 square meters workshop. It is established in 2000 and has convenient transportation access. We are fully committed to producing technologically advanced excavator parts and we have our own technical engineering research center and pile driving machinery engineering center. Our core team is composed of senior staff in the industry and has the international advanced R&D system and technical level. We are concerned on research and development to ensure that we can provide our customers with top quality and the innovative products.

Packaging & Shipping

We packed with standard wooden box, single module packed in individual small box and several box bundled into pallet.

FAQ



1. Q:How to chose the modules?

A: Please kindly advise your pile diameter, your pile concrete grade, and your project situation, we will help you to decide the numbers of the modules.



2. Q: Is your pile breaker dangerous for work?

A: Our machine operate contact-free and there is no impact force on the piles, so our machine is not dangerous for work.



3. Q:Is your module changeable or fixed?

A:Our module round pile breaker is changeable, you can combine freely according to your different pile diameter, the modules can be assembled and disassembled easily and conveniently.

We also can custom made for your small round piles which is fixed with 5 modules.



4. Q:Do you offer after-sale service?

A: Yes, we will offer you machine operation instructions. 6 months of warranty time will offer to our customer dating from the receipt day. Besides, we will offer some spare parts for free and life long technical instruction.



5. Q:Is your machine working with noisy?

A: We got CE approved and our machine working with low noisy which can meet environmental protection.



6. Q:your service ?

We can offer professional technical supports and good after sale service for your orders.

We have a stronger R&D team who can develop and produce the special machines according to your requests.
