Explosion-proof Factory Direct Sell Metal Tube Float Flowmeter for Various Gas/Liquid

FOB Reference Price:Get Latest Price
$200.00 - $500.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Sichuan, China (Mainland)
Brand Name:
Vacorda
Model Number:
LZ
Product Name:
Metal Tube Float Flowmeter
Output:
4-20mA
Accuracy class:
Standard:1.5; Special: 1.0
Diameter:
DN15~DN200
Explosion-proof grade:
None; Exia II CT5Ga; Exd II BT6Gb
Wiring connection:
M20X1.5 female thread; 1/2NPT female thread for Exd explosion
Power supply:
Standard: 24VDC; Battery type:3.6V lithium battery(3 years lifetime)
Connection form:
Stabndard:DIN2501 standard flange,special: customized
Type:
Local indication type; Remote type
Medium temperature:
Standard:-40~+100℃,PTFE:-50~100℃,High temperature type:110~450℃
Supply Ability
Supply Ability:
300 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard wooden box
Port
Shanghai/Shenzhen
Lead Time :
depends on the quantity of metal tube float flow meter

Explosion-proof Factory Direct Metal Tube Float Flowmeter for Various Gas/Liquid



Product Description

Metal tube float flowmeter consists of measuring pipe, float, indicator and process connection components with the characteristics of small size, wide measuring range, easy installation. In the industry area, it is widely used to measure flow of gas, liquid, and steam, especially suitable for mediums with low current velocity and low flow rate.



Product Parameters

Measuring range

Water:1~200000L/H(20°C)



Air: 0.03~6000m3/h (20°C, 0.1013MPa)

Measuring range proportion

Standard: 10:1

Accuracy class

Standard:1.5; Special: 1.0

Pressure class

Standard:DN15~DN504.0MPa; DN80~DN2001.6MPa



High pressure:DN15~DN5032MPa;DN80~DN20016MPa

Pressure loss

7kPa~70kPa

Medium temperature

Standard:-40°C~+100°C; PTFE:-50°C~+100°C



High pressure:110°C~+450°C

Medium viscosity

DN15:η<5mPa.s(F15.1~F15.3), η<30mPa.s(F15.4~F15.8)



DN25:η<250mPa.s; DN50~DN200:η<300mPa.s

Environment temperature

Remote type: -40°C~+85°C



On-the spot needle indicator: -40°C~+100°C

Connection type

Standard: DIN2501 standard flange; special: customize

Wiring connection

M20×1.5 female thread (1/2NPT female thread for Exd explosion-proof)

Power supply

Standard: 24VDC two-line 4~20mA(12VDC~32VDC)



Warning type:24VDC four-line 4~20mA(18VDC~18VDC)



AC type:85~265VAC 50HZ



Battery type:3.6V 7.5AH lithium battery(3 years lifetime)

Loading resistance feature

Two-line: max loading resistance=50×(voltage-12)Ω=600Ω 24V



Multi-line: max loading resistance 500Ω

Warning signal output

Reed pipe warning switch output,upper limit and lower limit flow warning

(contact capacity 1A 30VDC)



electric relay output(contact capacity 1A 30VDC, 0.25A 250VAC,0.5A 125VAC)

pulse output

Min space 50ms (max loading 100mA 30VDC, internal resistance 100Ω)

LCD display

Instantaneous flow display scope:0~50000



Total flow display scope: 0~99999999

Protection grade

IP65

Explosion-proof grade

Exia II CT5Ga   Exd II BT6Gb

Detailed Images



Related Products



Product Application







Company Information

Sichuan VACORDA Instruments Manufacturing Co., Ltd. is a professional production-manufacturing enterprise specialized in designing, producing and marketing of instruments and apparatuses. Our company has been established for 21 years since 1997 to grow up to be a team of high-quality, united, hard-working and truth-seeking characters. Solid foundation has been established.
