Factory CMOS sensor 2MP OV2640 Manufacturer price Camera Module

  • 10-49 Pieces
    $1.47
    $1.50
  • 50-199 Pieces
    $1.37
    $1.40
  • 200-999 Pieces
    $1.27
    $1.30
  • >=1000 Pieces
    $1.18
    $1.20
2% OFF Discount ends in : : :
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized packaging (Min. Order: 5000 Pieces)
Graphic customization (Min. Order: 5000 Pieces)

More

Lens Angle and Height (Min. Order: 5000 Pieces)
Customized logo (Min. Order: 5000 Pieces) Less
Samples: $1.40 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $1.40 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
Original
Model Number:
ov2640 camera module
Package:
SMT
D/C:
Newest
Type:
Module
Lead time:
In stock
Sensor type:
OV2640
Lead Free Status:
Lead free/RoHS
Effective pixels:
640x480
Connector:
send free as GIFT
Minimum illumination:
0.1Lux@(F1.2,AGC ON),0LUX with IR
Shipping by:
DHL\UPS\Fedex\EMS\HK Post
Payment:
Paypal/TT/Western Union/Credit card
Lowest price:
Plz contact us
Get datasheet:
Plz contact us

Packaging & Delivery

Selling Units:
Single item
Single package size:
3X2X1 cm
Single gross weight:
0.01 kg
Package Type:
1,the product is packed in electrostatic bags, 2,using a bubble wrap, 3,using carton packaging. In stock OV2640 CMOS Camera Module
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 5 To be negotiated
Video Description
Product Description

Factory CMOS sensor 2MP OV2640 Manufacturer price Camera Module

ov2640 camera module 3



 Features:



- Ultra-small 802.11b/g/n Wi-Fi + BT/BLE SoC module
- Low-power dual-core 32-bit CPU for application processors
- Up to 240MHz, up to 600 DMIPSDefinition of pin (please get it from the shop assistant):

OV2640 image sensor has 2 million pixels (1632x1232 pixels). It has small size and low working voltage. It provides all functions of a single UXGA camera and image processor. Through SCCB bus control, it can output 10-bit sampling data with various resolutions, such as whole frame, sub-sampling, window fetching and so on. UXGA images of this product can reach up to 15 frames per second. Users can completely control image quality, data format and transmission mode. All image processing functions including gamma curve, white balance, saturation and chroma can be programmed through SCCB interface. OmmiVision image sensor uses unique sensor technology to improve image quality and obtain clear and stable color images by reducing or eliminating optical or electronic defects such as fixed pattern noise, tail support, floating, etc.

High sensitivity for low illumination applications
Low Voltage Suitable for Embedded Applications
Standard SCCB interface, compatible with I2C interface
RawRGB, RGB (GRB4:2:2, RGB565/555/444), YUV (4:2:2) and YCbCr (4:2:2) output formats
Supporting UXGA, SXGA, VGA, QVGA, QQVGA, CIF, QCIF and sizes up to 40x30
Supporting VarioPixel sub-sampling
Functions of automatic impact control include automatic exposure control, automatic gain control, automatic white balance, automatic elimination of light stripes, automatic black level calibration. Image quality control includes color saturation, color phase, gamma, sharpness ANTI_BLOOM.
ISP has the function of eliminating noise and compensating bad points
Supporting image zooming
Compensation for lens loss of light
Self-regulation of saturation
Automatic adjustment of edge enhancement
Auto-adjustment of noise reduction
key parameter
Maximum Format UXGA of Photosensitive Array 1632x1232

IO voltage 1.7V-3.3V analog voltage 2.5-3.0v (internal LDO power supply 1.2V)
Power-consuming TBD Sleep < 20 UA
Temperature Operations - 30 to 70 degrees Celsius
Steady working from 0 to 50 C
Output format (8 bits) YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data
Optical Size 1/4“
Field of view angle 25 degrees
Maximum virginity 15 FPS SXGA

Sensitivity 1.3V/(Lux-sec)
SNR 40 dB
Dynamic RANGE 50 dB
Browse mode line by line
Electron exposure 1 to 1247 lines
Pixel area 2.2 um x 2.2 um
Dark Current 15 mV/s at 60℃
