Factory Directly liquid potassium carbonate filling machine manufacture

FOB Reference Price:Get Latest Price
$450.00 - $550.00 / Sets | 1 Set/Sets (Min. Order)
Power:
0.15KW
Model Number:
KA-YL
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Packaging Type:
Cartons, Cans, Bottles, Barrel, Stand-up Pouch, Bags, Pouch, Capsule, Case, Other
Packaging Material:
Plastic, Paper, Metal, Glass, Wood, Other
Type:
Filling Machine
Condition:
New
Application:
Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles, Other
Automatic Grade:
Automatic
Driven Type:
Pneumatic
Voltage:
110V/220V
Place of Origin:
Hubei, China (Mainland)
Brand Name:
KA PACK
Dimension(L*W*H):
133*50*45 cm
Weight:
30gkg
Certification:
CE ISO
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Name:
semi automatic liquid filling machine
Feature:
compact models ,saving place,h
Product name:
Liquid Pouch Filling Packing Machine
Function:
suitable for different liquid filling
Filling speed:
30-60 bottles/min
Processing Types:
Normal Pressure Filling
Advantage:
can be used for flammable and combustible liquid
Filling volume control:
by move adjuster knob
Filling machine wear part:
sealing ring
Material:
Stainless Steel 304/316
Supply Ability
Supply Ability:
20000 Set/Sets per Year
Packaging & Delivery
Packaging Details
KA PACK professional export wooden box.
Port
Shanghai/Ningbo port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 7 To be negotiated
Product Description

Description

The machine is piston liquid filling machine ,which is mainly suitable for filling liquid ,water ,juice,milk and other beverage. it's width used in food and medicine industry.The machine is made from SUS 304 .We also can customized the SUS316.



 Features

1,The structure of the machine is simple ,and you can adjust the filling volume and speed on the machine ;

2,The cylinder is from famous company AirTic .And other componets also is from famous brand in China;

3,About the filling head ,we adopt special technical to manufacture it,so that during using ,the material wouldn't will leak from filling head.so that hple you save material.

4,The volume of the machine is small ,easy to move it ,not need to install it with big room.it's suitable the small workshop and small business.

Technical parameters

Model

KA-YL 100

KA-YL 200

KA-YL 500

KA-YL 1000

KA-YL 2500

KA-YL 5000

Filling volume

5-100ml

10-200ml

50-500ml

100-1000ml

500-2500ml

1000-5000ml

Filling speed

50-60 bottles/min

40-50

bottles/min

35-45 bottles/min

30-40 bottles/min

25-35 bottles/min

15-25 bottles/min

Voltage

220/110V

50/60 Hz

220/110V

50/60 HZ

220/110V

50/60 HZ

220/110V

50/60 HZ

220/110V

50/60 HZ

220/110V

50/60 HZ

Filling accuracy

≤1%



≤1%

≤1%

≤1%

≤1%

Package size

1100*400*550

mm

1200*600*550

mm

1250*600*650

mm

1250*700*650

mm

1300*700*650

mm

1400*600*650

mm

Weight

25kg

30kg

35kg

45kg

50kg

60kg





Details of machine



Part one: filling nozzle



Part two: Air cylinder



Part three: oil and fog



Part four: Three valve

Usage

Packaging & Shipping

Shipping

INTERNATIONAL AIR MAIL

Payment

Fast Delivery

Different amount of time will be required for different

Company Information

About Us

Wuhan Ka Pack Tech Co,.Ltd.

Wuhan KA PACKING TECH CO,.LTD is a professional manufacture of packing and filling equipment for food, cosmetic, chemical and pharmacy. We have professional R&G department, QC, and after-sale team. our machines have been widely used in several fields throughout the world, such as food, pharmaceuticals, cosmetics, medical supplies, industrial foods, rubber goods, sundry goods, sporting goods, etc.

FAQ
Q

How can I get the sample to check your quality?

A

After price confirmation, you can require for samples to check our product’s quality. If you just need a blank sample to check the design and quality. We will provide you sample for free as long as you afford the express freight.

Q

What can I get the price?

A

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.

Q

What is your term of delivery?

A

We accept EXW, FOB Shenzhen or FOB Guangzhou. You can choosethe one which is the most convenient or cost effective for you.

Q

What about the lead time for the mass production?

A

Honestly, it depends on the order quantity and the season you place the order.
