Factory supplier automotive electronic printed multilayer circuit ceramic pcb

FOB Reference Price:Get Latest Price
$1.00 - $29.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 50000 50001 - 350000 350001 - 750000 >750000
Est. Time(days) 3 7 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LYH
Model Number:
Customized
Base Material:
ceramic,FR-4,High TG,Resin,etc
Copper Thickness:
0.5oz, 1oz, 2oz, 3oz
Board Thickness:
1.5mm+/-0.1mm
Min. Hole Size:
0.15mm
Min. Line Width:
0.075mm
Min. Line Spacing:
0.075mm
Surface Finishing:
HASL,OSP,ENIG,gold finger,etc.
Product name:
ceramic pcb
Product Keywords:
pcb
Certificate:
UL,ISO9001, ISO14001,OHSAS1
Number of Layer:
Customized, up to 16
Application:
power,industry,automotive
Color:
Green
Function:
Data Transfer
Board thickness:
0.3-3.5mm
Impedance tolerance:
±10%
MOQ:
1
Supply Ability
Supply Ability:
100000 Square Meter/Square Meters per Month ceramic pcb
Packaging & Delivery
Packaging Details
Vacuum and Bubble package,and then in high quality cartons.
Port
Shenzhen, Nanchang, Jiujiang, Ganzhou
Lead Time :
Quantity(Pieces) 1 - 50000 50001 - 350000 350001 - 750000 >750000
Est. Time(days) 3 7 15 To be negotiated
Video Description
Product Description

Factory supplier automotive electronic printed multilayer circuit ceramic pcb

Advantages

1. Professional high precision PCB & PCBA manufacturer.
2. Core team with more than 10 years rich experience in PCB & PCB assembly industry
3. High & stable quality products

4. Prompt delivery

5. Competitive and reasonable price
6. Good after-sales Service

Technical Specifications Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
LYH
Model Number:
Customized
Number of Layers:
Customized, up to 16 Layers
Base Material:
ceramic,FR-4,Resin,Halogen free,High TG etc
Copper Thickness:
0.5oz, 1oz, 2oz, 3oz,etc.
Board Thickness:
1.5mm+/-0.1mm
Min. Hole Size:
0.15mm
Min. Line Width:
0.075mm
Min. Line Spacing:
0.075mm
Surface Finishing:
HAL/HAL LF,OSP,ENIG,Immersion,etc.
Laminate:
ceramic,FR-4,Halogen free,High TG etc
Max. Pannel size:
22×32 (558mm×812mm)
Board thickness:
0.3-3.5mm
Solder mask color:
Green,Black,Blue,Red,white etc.
Board thickness Tol.:
±10%
Stackup alignment:
±2mil (±50μm)
Min.Via/PTH ring size:
6mil (0.15mm)
Min.line space/width:
3mil/3mil (0.075mm/0.075mm)
Max.PTH hole size:
5.0mm
Min.inner layer PAD:
4mil (0.1mm)
Min.inner layer thick:
4mil (0.1mm)
Inner layer Cu thick:
0.5-2.0 oz
Hole wall thick:
18-30μm
HAL(LF) tin thick:
150-1000u (3.75-25μm)
Outlayer Cu thick:
0.5-3.0 oz
Min.drill hole:
0.15mm
Hole to hole position:
±2mil (±50μm)
Hole tolerance:
±2mil (±50μm)
Inpendence control tolerance:
±10%
Etching tolerance:
±10%
Through hole aspect ratio:
10:1
Max.pulg via hole:
0.5mm
PAD alignment accuracy:
3mil/3mil (0.075mm/0.075mm)
Testing:
100% E-Testing
Min.solder mask bridge:
3mil (0.075mm)
ENIG thick:
Au:1-3u,Ni:100-300u
Max. hard gold thick:
30u" (0.75 μm)
Max. twist & warp:
0.75%
Capacity:
up to 100,000㎡/month
Surface finish:
HAL/HAL LF,OSP,ENIG,Immersion gold/silver/Tin/Au(EING), HASL, Gold finger board, Au plating board,Tin/Ce plating board,Carbon oil board,HAL,Naked Board,Bare copper,etc
Related Products



Company Information
Our Service
Application

Our products are widely used in automotive electronics,industrial control,power supply,medical device,LED,security,aerospace,IOT,GPS tracking device and so on.
