Factory supply 1000L craft commercial beer brewing equipment

FOB Reference Price:Get Latest Price
$3,700.00 - $40,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
HBET- 1000L
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 50 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
HBET
Processing Types:
Alcohol
Voltage:
220/380V or customization
Power(W):
70KW
Dimension(L*W*H):
60 cubic meter
Weight:
5000KG
Certification:
CE ISO
Warranty:
5 Years
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Name:
Factory supply 1000L craft commercial beer brewing equipment
Brewhouse type:
2/3/4 vessels
Material:
SUS304/316/Red Copper
Function:
Brewing Beer Brewing Equipment
Heating method:
Steam Heating
Control system:
PID/PLC
Cooling way:
Dimple Plate Cooling
Cooling media:
Glycol water
Tank welding process:
Automatic
Supply Ability
Supply Ability:
20 Set/Sets per Month Factory supply 1000L craft commercial beer brewing equipment
Packaging & Delivery
Packaging Details
Plastic paper firstly then outside with iron frame ( standard wooden case) for LCL
Plastic film wrapped and steel frame fixing for FCL
Port
Qingdao/Tianjin/Shanghai/Ningbo/Shenzhen port and so on
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 50 To be negotiated

Factory supply 1000L craft commercial beer brewing equipment



Product Description


Hot Sale 1000L Brewery Equipment With Two Vessel





Hot Sale 1000L Brewery Equipment With Three Vessel





Hot Sale 1000L Brewery Equipment With Combi-brewhouse





Send Inquiry>>

Click Here Contact Me Now!!!

1000L brewhouse can be in various combination:

1. Two vessels: Mash/lauter tank, Kettle/whirlpool tank;
2. Three vessels: Mash/lauter tank,whirlpool, Kettle; Or Mash tun, Lauter tank, Kettle/whirlpool tank;
3. Four vessels: Mash tun, lauter tank, kettle, whirlpool tank;

Here we introduce the 1000L brewhouse bases on two vessels



1000L brewhouse has three kinds of heating way:

1. Electric heating
2. Steam heating
3. Direct fire heating



Here we introduce the heating way bases on electric heating.



1000L brewery equipment maily consists of malt milling system, brewhouse, fermenting system, cooling system, CIP system, and controlling system and other auxiliary system.







Milling system

Malt miller

300-500kg/h

1pcs

Auger(option)

Ability is 1000KG/h

1pcs

Hopper(option)

Volume is 0.6m3. SUS 304 with pre-masher

1pcs

Brewhouse

Mash tun/ Lauter tank

Volume is 1000L, with false bottom, grant, raker with motor

1pcs

Kettle/whirlpool tank

Volume is 1000L, electric heating

1pcs

HLT water tank

Volume is 2000L, electric heating

1pcs

Includes plate heat exchanger, wort pump, motors, hops filter, yeast adding tank, oxygen device and pipelines

Fermenting

Fermenters

Volume is 1000L or 2000L (double batches)

6pcs

BBT(option)

Volume is 1000L or 2000L (double batches)

2pcs

Racking arm, spunding valve, pressure gauge, carbonation stone, sample valve

Cooling system

Glycol tank

Volume 2000L or 3000L

1pcs

Cold water tank(option)

Volume 2000L, cooled by glycol tank

1pcs

Chiller

5HP, Copeland

2pcs

Cleaning

CIP

100L two tanks, heated by electric, with pump and trolley

1pcs

Controlling

Control cabinet

PLC touch screen or PID controller

1pcs



1. Malt Milling System
Malt Mill: Material: carbon steel and chrome plate roller;
Double roller type malt milling machine;
Equipped with motor, belt pulley, belts, etc; Auger and hopper is option.
Working capacity: 300~500kg/h

2. Mashing System





3. Fermentation System

4. Cooling System

No.

Item

Introduction

01

Glycol water tank

Generally the capacity is the three times of brewhouse.

02



Chiller

According to glycol water tank's capacity

World famous brand--Australia COOLSOON, the quality is highly excellent, cooling efficient is the best. If there have something wrong in the future, it is easy to find spare part.

03

Function

Glycol water tank and Chiller will work rogether, to keep cooling wort in the plate heat exchanger.





5. CIP System
Disinfection Tank:
Material is SUS304;
Thickness is 2mm;
Weld slinging band;
Material all adopt the international standard of 304 stainless steel, all welding are argon protection single-sided, double-sided forming.

Alkali tank:
Material is SUS304;Thickness is 2mm;
Weld slinging band; Valves, accessories supporting;
Material all adopt the international standard of 304 stainless steel, all welding are argon protection single-sided, double-sided forming.

6. Control System
Control Cabinet:
All specification is decided according to whole brewing system.



Quality Control

Beer Making Process



Company Information

1. Company Profile:





2. Certificates

3. Factory:



4. Customer case

Send Inquiry>>

Click Here Contact Me Now!!!
