Fiber Optic Equipment 1550nm fiber optical transmitter

FOB Reference Price:Get Latest Price
$985.00 - $1,850.00 / Pieces | 1 Piece/Pieces 1550nm optical transmitter (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
SOFTEL/OEM
Model Number:
ST1550I
1550nm transmitter module::
direct modulate
1550nm transmitter connector::
FC, SC
1550nm transmitter Bandwidth::
47-862MHz
Optical power range::
2mw-32mw
Network interface port::
RJ45 or RS232
Wavelength::
1550nm
1550nm transmitter SBS::
>=17dBm
fiber optic rf transmitter flatness::
≤±0.75(dB)
optic rf transmitter input impedance::
75Ω
Product name:
Fiber Optic Equipment 1550nm fiber optical transmitter
Supply Ability
Supply Ability:
2000 Piece/Pieces per Month 1550nm optical transmitter
Packaging & Delivery
Packaging Details
Standard export carton
Port
SHANGHAI/NINGBO
Lead Time :
15 DAYS
Product Description



Fiber Optic Equipment 1550nm fiber optical transmitter



1. Low chirp effect, high linearity DFB laser
2. Dual Module therefore drive, chirp compensation
3. Laser OMI AGC/MGC
4. Intuitional modulation status display
5. Dual power supply inside backup. Full-automatically swicth
6. Full-automatically control of casing temperature





Performance

Index

Supplement

Optic feature

Laser wavelength

(nm)

1550±10



Linearity width

(MHz)

≤1

(λ)

Equivalent noise intensity

(dB/Hz)

≤-160

RIN (20~1000MHz)

Side mode suppression ratio

(dB)

≥35

SMSR

Extinction ratio

(dB)

≥20

Xp

Output power

(dBm)

2×7

1×71×102×62×7

SBS restrain

(dBm)

≥17



Return loss

(dB)

≥60



Optic fiber connector



FC/APC

SC/APC or E-2000

RF feature

Work bandwidth

(MHz)

45-862



Input level

(dBmV)

18~28

AGC

Flatness

(dB)

≤±0.75

45~862MHz

Return loss

(dB)

>16

45~750MHz

Input impedance

(Ω)

75



Link feature

Transmit channel



PAL-D/60ch



CNR

(dB)

≥51

10Km optic fiber,0dBm receive

CTB

(dB)

≤-65



CSO

(dB)

≤-60



General feature

Network interface port



RJ45,R232

Support I.E. & SNMP

Power supply

(V)

90~265 city power

-48VDC optional

Power Consume

(W)

≤50

Single power works

Work temp.

()

-5~65

Machine temp controlled automatically

Storage temp.

()

-40~85



Work relative temp.

(%)

5~95



Size

(")

19×10×1.75

(W)x(D)x(H)
