GRB0.7X1.7mmC manual die cutting creasing matrix channel

  • 100-199 Boxes
    $22.00
  • 200-299 Boxes
    $20.00
  • >=300 Boxes
    $18.00
Quantity:
- + Boxes available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Samples - $18.00 /Box, 1 Box (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Model Number:
GRB0.7X1.7mmC
Place of Origin:
Beijing, China
Brand Name:
Graphic
HS NO.:
39169090
Color:
White
Weight:
1.4kg/box
Punching time:
20000-50000
Channel Height:
0.7 mm
Channel Width:
1.7mm
Certificate:
SGS
Industrial use:
cosmetic
Application:
For carton and box making
Name:
GRB0.7X1.7mmC manual die cutting creasing matrix channel

Packaging & Delivery

Selling Units:
Single item
Single package size:
73X22X21 cm
Single gross weight:
13.0 kg
Picture Example:
package-img
Lead Time :
Quantity(Box) 1 - 1000 >1000
Est. Time(days) 7 To be negotiated
Video Description
Specifications

Featrues:

 1. World's most advanced creasing matrix made from plastic, pressboard and fibre for various die cutting jobs
2. Accurate locator – ensures perfect registration
3. Low profile chamfer – board flows freely over the matrix; board marking is reduced
4. Finger lift adhesive tape – backing paper easily and quickly removed
5. New and strong adhesive removes cleanly from the plate after use, will not move about during die cutting jobs
6. Special sizes available to suit all board types, off-centers and multi-crease for close creasing rule
7. It is extremely durable and accurate and provides benefits in time and cost.
8. Competitive price with high quality
9. Incredibly durable for short-run job with average punching times from 20,000-50,000
10. Off center, double matrix and mtrix on reels are available upon demands

Size Table:

Plastic-based Matrix Size
Unit
Base Width(mm)
GRB0.2*0.8
Box
12
GRB0.3*0.8
Box/Coil
12
GRB0.3*1.0
Box/Coil
12
GRB0.3*1.1
Box/Coil
12
GRB0.3*1.2
Box/Coil
12
GRB0.3*1.3
Box/Coil
12
GRB0.4*1.0
Box/Coil
12
GRB0.4*1.1
Box/Coil
12
GRB0.4*1.2
Box/Coil
12
GRB0.4*1.3
Box/Coil
12
GRB0.4*1.4
Box/Coil
12
GRB0.4*1.5
Box/Coil
12
GRB0.5*1.2
Box/Coil
12
GRB0.5*1.3
Box/Coil
12
GRB0.5*1.4
Box/Coil
12
GRB0.5*1.5
Box/Coil
12
GRB0.5*1.6
Box/Coil
12
GRB0.6*1.7
Box/Coil
12
GRB0.7*2.1
Box/Coil
12
GRB0.7*2.3
Box/Coil
12
GRB0.8*2.5
Box/Coil
12
GRB0.8*2.7
Box/Coil
12
GRB0.8*3.0
Box
12
GRB1.0*3.0
Box
12
GRB1.0*3.2
Box
12
GRB1.0*6.0
Box
12
GRB1.4*7.0
Box
12
How to choose

Method to choose creasing matrix size for cardboard paper.Size table(subjct to 23.8mm die-cutting rules).

For instance:the thickness of the cardboard:0.52mm;the thickness of creasing rules:0.71mm,according to calculation formula:A=0.52≈0.5(mm);B=0.52*1.5+0.71=1.49≈1.5(mm),so we should choose the size of 0.5*1.5

Method to choose creasing matrix size for corrugated paper.Size table(subjct to 23.8mm die-cutting rules).

How to use Creasing Matrix

1.Measure the length of the creasing rule.
2.Mark the measurement and cut the matrix.
3.Mount the cut piece onto the creasing rule with locator.
4.Remove backing strip to revel adhesive membrane
5.Lock into press&index machine to place matrix on machine to place matrix on opposing platen.
6.Remove locator strip by pulling firmly upwards.
7.Mitre to suitable angle.

Product information

Item Name
High Quality Creasing Matrix( Imported Finger lift tape and glue)
Matrial
Plastic
Base color
White/Yellow
Customer Design
Welcome
Sample
Available
Sample Price
Free
Sample Last Time
About 3 days
Payment Terms
TT/Westerm union/Money Gram
Production Time
2-5 days
Delivery Port
Tianjin or Shanghai
Finished product
About us

    Beijing Graphic International Trade Co., Ltd is a joint venture created by Changzhou Machinery Blade Co.,ltd and ChangZhou Xinyitong Electrical & Mechanical Technology Co.,ltd, who is one of the world's leading and professional supplier of printing equipments and consumables in China, providing its customers with Graphic Arts Consumables, Machines and Spare Parts for diversified jobs.
    Since its establishment in 2008, Beijing Graphic International Trade Co., Ltd is firmly in accordance with the Business Spirit"Excellent Quality, First-class Service, Honest Commitment"and remain committed to heartfelt Management Principles"Customers Supreme, Reputation First", meanwhile, we undertake"Action Priority, Efficiency Persistence"as our Enterprise Criterion.
    We are always striving for new ideas and innovative solutions. Beijing Graphic Trade stands for efficient processing ,printing and die cutting systems for most versatile applications with highest customer benefits.
    Here,Beijing Graphic International Trade Co., Ltd works on things that matter. The best people and the best technologies are taking on the toughest challenges. You will find exactly the right solution for every application and material.

Exhibition

Certification

Related Products
Packing & Delivery

Packing:70cm/pc
               50pcs/box
               1.3kgs/box
               10boxes/carton
               Carton: 73x 22 x 21cm(length x width x height)
               500- 700boxes/pallet
Delivery:Within 2-7 days upon receive payment
