Halogen free wire XLPE insulated awm UL3385 cable

FOB Reference Price:Get Latest Price
$0.10 - $0.60 / Meter | 6100 Meter/Meters (Min. Order)
Lead Time:
Quantity(Meters) 1 - 100000 100001 - 500000 500001 - 1000000 >1000000
Est. Time(days) 15 20 30 Negotiable
Samples:
$0.01 /Meter | 1 Meter (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
DIANHANG
Model Number:
UL 3385
Type:
Insulated
Application:
Heating
Conductor Material:
Copper
Conductor Type:
Solid
Insulation Material:
XPLE
Product name:
Halogen free wire XLPE insulated awm UL3385 cable
Rated temperature:
105'C
Rated voltage:
300V
Color:
Optional
Conductor:
tinned copper wire
Insulation:
XLPE Insulation
Flame Test:
UL VW-1,CSA FT1,JQA F-Mark
MOQ:
6100M
Length:
1830m/spool
Specification:
30-16AWG
Supply Ability
Supply Ability:
100000 Kilometer/Kilometers per Year
Packaging & Delivery
Packaging Details
According to different OD, there will be different standarded packing length as 610m/Roll, 305m/Roll, 100m/Roll,1830m/Spool,3660m/Spool. Usually, wire diameters above 1.0 are rolled and axles below 1.0 are rolled.
Port
shanghai
Lead Time :
Quantity(Meters) 1 - 100000 100001 - 500000 500001 - 1000000 >1000000
Est. Time(days) 15 20 30 To be negotiated
Video Description



Product Description

 UL3385Halogen free crosslinked wire

Rated temperature:105

Rated voltage:300V

Reference standard:UL758,UL1581,CSA C22.2No.210.2

Solid or stranded, tinned or bare copper conductor 30~10AWG

XLPE insulation, comply with ROHS, REACH environmental standard

Passes UL Horizontal, and CSA FT2 flame test

Uniform insulation thickness to ensure easy stripping and cutting

Application:

For general purpose internal wiring of appliance

UL Typeconductor   insulation

max.cond

resistance

compressive

strength

3385

  specification

     (AWG)

construction    ODthickness

   OD

   (Ω/Km,20℃,Dc)     (Vac,1min)
    (mm)(mm)(mm)
307/0.100.30.401.103812000
287/0.1270.380.411.202392000
267/0.160.480.411.301502000
247/0.200.60.401.4094.22000
227/0.2540.760.421.6059.42000
207/0.320.940.411.7536.72000
1816/0.2541.170.462.1023.22000
1626/0.2541.490.462.4014.62000
