Handheld two way radio digital walkie talkie dmr

FOB Reference Price:Get Latest Price
$10.00 - $99.00 / Units | 2 Unit/Units (Min. Order)
Color:
Lead Time:
Quantity(Units) 1 - 500 >500
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 100 Units)
Customized packaging (Min. Order: 100 Units)

More

Configuration (Min. Order: 100 Units)
Color (Min. Order: 100 Units)
Specification (Min. Order: 100 Units) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
WANHUA
Model Number:
ATS320
Type:
Handheld
Dimensions:
127*62*35mm
Frequency Range:
UHF: 400 - 470 MHz
Storage Channel:
256 Channels
Talk Range:
5-10km
Warranty:
1 Year
Product Name:
Wanhua walkie talkie
Output Power:
0.5 W
Battery capacity:
1500 mAh (Lithium-Ionen-Akku)
Frequency stability:
±2ppm
Antenna impedance:
50 Ω
Programmable keys:
2
Operating voltage:
7.4 V (nominal)
Transmitting power:
UHF: 1 / 4 W
Audio sensitivity:
+1 dB to -3 dB
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month professional FM Transceiver
Packaging & Delivery
Packaging Details
car key remote standard packing or as customer's requirements
Port
xiamen
Lead Time :
Quantity(Units) 1 - 500 >500
Est. Time(days) 15 To be negotiated

Handheld two way radio digital walkie talkie dmr

Application scenario



Product parameters



General data

Frequency range

UHF: 400 - 470 MHz

Supported operation modes

· DMR Tier II (DMR conventional), Simulcast

· Analog

Channel capacity

256

Zone capacity

16

Channel spacing

12.5  kHz (analog)
12.5 kHz (digital)

Operating voltage

7.4 V (nominal)

Battery

1500 mAh (Lithium-Ionen-Akku)

Frequency stability

±2ppm

Antenna impedance

50 Ω

Programmable keys

2

Transmitter

Transmitting power

UHF: 1 / 4 W

Modulation

11 K0F3E at 12.5 kHz

4FSK digital modulation

12.5 kHz (voice & data): 7K60FXW

Interfering signals and harmonics

-36 dBm < 1 GHz
-30 dBm > 1 GHz

Modulation limiting

±2.5 kHz at 12.5 kHz

Noise suppression

40 dB at 12.5 kHz

Adjacent channel selectivity

60 dB at 12.5 kHz

Audio sensitivity

+1 dB to -3 dB

Nominal audio distortion

≤ 3%

Digital vocoder type

AMBE+2

Receiver

Sensitivity (analogue)

0.22 μV (12 dB SINAD)

Sensitivity (digital)

0.22 μV / BER 5%

Adjacent channel selectivity
TIA-603
ETSI


60 dB at 12.5 kHz / 70 dB at 20 and 25 kHz
60 dB at 12.5 kHz / 70 dB at 20 and 25 kHz

Intermodulation


70 dB at 12.5/20/25 kHz

Spurious response rejection

70 dB at 12,5/20/25 kHz

Spurious response rejection

40 dB at 12.5 kHz

Nominal audio power output

0.5 W

Nominal audio distortion

≤ 3 %

Audio sensitivity

+1 dB to -3 dB

Conducted spurious emission

< -57 dBm

Ambient data

Operating temperature range

-30 °C to +60 °C

Storage temperature range

-40 °C to +60 °C

ESD

IEC 61000-4-2 (level 4)
±8 kV (contact discharge) ±15 kV (air discharge)

Protection against dust and moisture

IP54

Product Description


Our Services

Shipping terms
1-2 days for sample order, 3-5 days for bulk order
Customer Service
1. OEM&ODM service offered
2. Sample’s fee can be refunded after order reaches 1000 sets
3. Delivery can be express: DHL, UPS,FedEX, EMS,TNT
Warranty
Before delivey, we will check the item’s quality strictly one by one. Life –warranty for radio host & accessories, please contact us immediately when you get defective, thanks.
Payment terms
Payment: Paypal, T/T, Western Union (please do not believe anybody by E-mail say our bank change, thank you)

Company Information

Packing Details

Packing Details:

1 x Host
1 x Li-ion Battery Pack
1 x Antenna
1 x Belt Clip
1 x Use’s Manual
1 x Desktop Charger ( 110V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
1pc color box
40pcs per Carton
Carton size:48.5*42*67cm

FAQ

1.Q: Can you offer free sample to test?
A: In General, for new customer you pay the sample fee first, but when your order reach required amount we refund the sample cost to you.

2. Are you a trade company or a manufacturer?
A: We are an R&D based creative and productive manufacturer specialized in CE/FCC/ TELEC approved walkie talkie.

3.Q: What's your best price?
A: Our products have a quite wide price range for different types and different quality requirement. so contact us freely, we will be happy to give you a quotation upon receipt of your detailed requirements.

4.Q: Quality control ?
A: You can be assured of the quality .Because we tested one by one before send out the goods .

5. Q: Does your products have related Certificates?
A: Yes, normally we have CE/FCC/TELEC/Rohs certificates. Once needed, we will try to provide the certificate as our sincerely customers required.
