Helmet 5mm with flange series Lamp LED

FOB Reference Price:Get Latest Price
$0.0025 - $0.05 / Piece | 100000 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Type:
LAMP LED
Model Number:
LS-LD5C4
Chip Material:
see below
Emitting Color:
see below
Luminous Intensity:
1000-2000mcd
Luminous Flux(lm):
7-8lm
Optical Attenuation(%):
0
Power:
0.06W
Power Dissipation:
0.08
Viewing Angle(°):
100
Color Temperature:
Customers' Requirements
Operating Temperature(℃):
-20 - +85
Storage Temperature(℃):
-30 - +85
Place of Origin:
Guangdong, China
Brand Name:
LENSTAR
Certification:
ce, RoHS
Peak Forward Current:
100mA
Soldering:
260℃, 3mm out of physical body ≤3s
Color Rendering Index(Ra):
80
Supply Ability
Supply Ability:
60000000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
1,000PCS/Static Bag, 7000PCS/Inner Box, 5Boxes/CTN
Port
Shenzhen
Lead Time :
3-7days
Product Description

The Helmet 5mm with flage series Lamp LED are available with different colors. T1 (4.8X4.4mm) standard package. Utilizing advanced LED chip technology. The white LED which was fabricated using a blue LED and a phosphor, and the phosphor is excited by blue light and emits yellow fluorescence the mixture of blue light and yellow light results in white emission Ideal for Automotive Lighting, Traffic Lamp, Electronic Signals, Special Lighting ... ...

Size

* All size in milimeter, tolerance +/- 0.1mm.

Parameters

P/N

CHIP

Emitting Color

Lens

Forward Voltage

Wavelength

Luminous intensity

Viewing

Angle

Min

Max

Min

Max

Min

Max

LS-LD5C4CRS5J-4.4H

InGaAlP

Red

Clear

1.80

2.40

620

640

200

800

100

LS-LD5C4COS5J-4.4H

InGaAlP

Orange

1.80

2.40

600

620

200

800

LS-LD5C4CYS4J-4.4H

InGaAlP

Yellow

1.80

2.40

580

600

200

700

LS-LD5C4CBS4J-4.4H

InGaN

Blue

2.80

3.60

460

480

200

600

LS-LD5C4CGL2J-4.4H

InGaAlP

Yellowish Green

1.80

2.40

560

580

100

300

LS-LD5C4CGSCJ-4.4H

InGaN

Pure Green

2.80

3.60

500

535

800

3000

LS-LD5C4CWXCJ-4.4H

InGaN

White

2.80

3.60

2500K

20000K

800

3000

Packaging & Shipping

 All the items will be shipped within 3-7 working days for samples, 10-30days for batch, except Chinese weekend or holiday. All the items will be 100% tested carefully before shipping.

Generally 5-8 working days via Express, 14-20 working days via AirMail. 30-40 working days via economical post.

Due to shipping policies change frequently, we will send out clients' parcel by similar efficiet forwarder if our promised method is failed to ship out. For example, we might change Singapore Post to Netherland Post, Swiss Post or Sweden post. Sometimes Netherland/Swiss/Sweden is much faster and has less customs problems.

If you have not received your items within 40 working days, please contact us. We will track the shippment and get back to you as soon as possible with a satisfying reply.

Buyers are responsible for (in case) all additional customs fee or taxes in their country. These additional fees maybe charged at the time of delivery. We will not refund shipping charges for refused shippments.

The shipping cost is not including any import taxes, so the buyers should be responsible for Customs duties.

We ship to worldwide, except APO/FPO. Please kindly check your address carefully before placing order, we will not responsible for additional remote charges which will usually cost USD35.

Company Information

Dongguan Lenstar Opto-Electronics Co., Ltd. has been dedicating to be a professional manufacturer, designer, exporter of LED Diodes, LED Lights and LED related products in Dongguan, China since her establishment of 2010. LENSTAR is situated at Dalang Town, Dongguan City. We strictly pursue our policy of "first-class quality, the best credit". Through hard work and innovation, our company is now composed of hundreds of staff members and occupis more than 1000 square meters. She has a well-trained team and international advanced equipments to ensure the quality of products. The entire production process is strictly monitored and 5 steps of QC testing is our standard policy to supervise the quality. The advanced temperature testers, luminance testers and photoelectric instruments are adapted to conduct strict testing such as voltage withstand, shock proof andsalt spray tests. All our operations are according to ISO9001:2000 and ISO14000 systems. Our qualification rate is above 99.8%. Al our products comply with CE standard and the RoHS Directive.



Our Services

High quality:LENSTAR have a strict quality control system, every product have 8-24hours aging test before shippment. We select the best quality rawmaterials for our products, such as PPA or EMC type lead frame, Bridgelux's or Epistar's chip as the core, gold wires for bondng, etc.

Best price: We are one of professional LED factories in China. All the prices are wholesale price. Our target is producing high quality goods as well as best price to benefit our clients.

Fast response:  Any question of our products will be replied in 24 hours except the social holidays.

Promptly delivery: 3-7 working days for samples. 10-30days for batch

Good after sales services: Once there is any bad defect during your usage or the new goods go bad, we will solve it for you or send you a new one for free.

OEM & ODM services: We have own designer, and we offer OEM & ODM service too.

Quality warranty: Quality guarantee is based on storing, installing, operating and maintaining correctly in the normal operation condition. It is not included in our maintaining range when installing inappropriately, breaking the operating rules, and leading to the products damaging. LENSTAR will maintain the right to either repair, parts replacing or products exchange during the quality warranty period. The parameter of specification is according to the sample only for reference.

Notice

The Pins of LED can be bent where is at least 3mm out of LED colloid.

The Pins of LED would be scraped by the kinked tools easily, where the LED bracket is rusting, especial expose it in moist air. To decrease the LED bracket rust, we are advising to be plated LED bracket tins.

Be careful of some chemical results in the LED colloid faded and damaged when using checmical clean the LED, such as Trichloroethylene, Acetone etc. It can use ethanol to clean LED, but the peroid not exceed 3 minutes.
