High Lift 12v Mini Circulating Water Pump For CNC Equipment Cooling Circulation

FOB Reference Price:Get Latest Price
US $35-41 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Shenpeng
Model Number:
P6037
Theory:
Centrifugal Pump
Structure:
double-stage pump
Usage:
Water
Power:
Electric
Standard or Nonstandard:
standard or customized
Fuel:
DC electricity, battery, solar panel
Pressure:
High Pressure
Application:
Hot or cold water circulation/boost
Voltage:
12V/24V
Motor:
DC Brushless Motor
Flow rate:
14 - 19L/M
Max head:
18-27M
Certificate:
CE / ISO 9001 / FDA
Feature:
High Flow,Food grade
Material:
PPE
Color:
Black
Warranty:
2 Years
Name:
Pump For CNC Equipment Cooling
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Each piece in bubble bag,then put in outer carton+pallet
Port
Shenzhen,HongKong
Lead Time :
30 days after receiving the deposit
Video Description

High Lift 12v Mini Circulating Water Pump For CNC Equipment Cooling Circulation

6037_016037_026054

Type

P6037

Rated Voltage

12V / 24V

Voltage Range

8-20V / 12-30V

Max Flow

14L/min, 19L/min

Max Lift

18m / 27m

Max Noise

45dB / 55dB

Motor Type

DC Brushless Motor

Food Grade(Y/N)

Y

Liquid Temperature

0-70

Ambient Temperature

-25-70

Pump Theory

Centrifugal Pump

Medium

Hot or cold water, beverage, oil, antifreeze

Protection Level

IP68

Using Place

Indoor / Outdoor

Power Consumption

84W / 114W

Service Life

20000 hours

OD of inlet

22.0mm

OD of Outlet

19.2mm

Dimension

156*97.6*75mm

Power supply

Battery / Electric / Solar panel

Structure

Single-stage

Material

XYRON PPE

Customized functions

1, Dry-running protection

2, Submersible

3, PWM speed adjustable

4, FG signal output

5, Locked-rotor protection

Remarks

Not self-priming

6037_036037_04

Data sheet
Rated VoltageVoltage RangeRated CurrentMax HeadMax FlowRated PowerMax Noise
VVAmL/minWdB(A)
128-207181484≤45
2412-3062719114≤55

6037_0513501_083501_093501_10
