High Quality 1200L industrial beer brewing system micro brewery beer brewing kettle

FOB Reference Price:Get Latest Price
$35,000.00 - $84,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
1200L
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
SLET
Processing Types:
beer
Voltage:
customized
Power(W):
10KW
Dimension(L*W*H):
According to the Capacity
Weight:
1~5 Tons
Certification:
CE,PED,LVD
Warranty:
3 Years
After-sales Service Provided:
Field installation, commissioning and training, No overseas service provided
Name:
Microbrewery
Material:
Stainless Steel 304
Application:
Brewpub
Heating way:
Electrical Heating
tanks thickness:
inner 3mm outer 2mm
Supply Ability
Supply Ability:
12 Set/Sets per Month
Packaging & Delivery
Packaging Details
PE film,wooden case,iron container
Port
Qingdao
Video Description
Our beer brewery equipment can brew any beer you want
Tell me your request,I will give you the best beer.
Welcome to visit our factory.
Product Description



The whole beer equipment is consisted of Mash system,Fermentation system,Refrigeration system,Control system and CIP cleaning system. The tank of the system all adopts Red copper and S.S 304,and the system also have high automatic control capacity.

Simple operation,PLC automatic control system ,PLC semi-automatic control system.

Equipments characteristics:small investment.quick effectiveness,high quality,lower prices,the investment repayment is fast,the service life of equipment is long,easy operation,lower cost.Strong technical force.

At the same time if you have requirements,we could design and produce the products you need!



The Brewing process



1.(1)Infiltrating ,crushing malt
   (2)Heating the brewing water in brew kettle
2.(1)Pumping a certain amount of appropriate temperature of hot water into mash tun
   (2)starting rotary blade,uniformly putting into material ,stopping rotary blade when stirring uniformly .timing saccha
   (3)Controlling of water temperature and water quantity,keeping appropriate saccharification temperature ,stirring in every 15 minutes
3.(1)refluxing turbid wort when saccharification ends .observing through the sight glass, beginning to filter when wort is charified
   (2)washing the tank when the tank exposes in the filtration process ,water temperature 78
   (3)Continue to filtrate after washing the tank,until sugar content meets the requirements.stopping washing the tank and filtrating
4.(1)pumping all the wort into brew kettle ,heated to boiling for 60 to 90 minutes
   (2)in the first ten minutes of boiling,batch adding bitter hops
   (3) adding sweet hops before the end of boiling

5.(1)after the end of boiling,immediately pumping wort into lauter tun&whirlpool tank.
   (2)starting to cyclotron precipitation,lay aside for 30 minutes
6.(1)starding cold water valve and wort pump at the same time,cooling wort to a certain temperature in the plate heat exchanger
   (2) after wort is cooling ,oxygenating to 8mg/l,pumping wortto fermentation tank
   (3)adding special beer yeast into fermentation tank to ferment
7.(1)controlling fermentation temperature and pressure,when brix  drop to 4.2,sealing tank to maintain pressure,automatically heating up to 12 °C,deoxidating cold diacetyl
   (2)at the end of deoxidating cold diacetyl,cooling uniformly and slowly,precipitating yeast in this process
   (3) wine temperature drop to 1 to 2 °C can be stored,tank bottom  yeast mud can be recycled

beer equipment list

Eqiupment List1.0                                   Model
Eqiupment List
1.0
Milling
System
Malt Mill300Kg/hCIP Cleaning
System
Washing Tank1HL/2pcs
Work BinaccessoryWashing Pump3m³/h
Mashing
System
Mash Tun1200LPipeline&valvesaccessory
Lauter Tun1200LCooling
System
Ice Water Tank3500L
Wort Pump5m³/hCooling Machinery5HP/2sets
Heat Exchanger12m²Ice Water Pump1.7m³/h
Wort OxygenatoraccessoryPipeline&valvesaccessory
Assemble PipelineaccessoryControl
System
DCS Stylebox2000*700*400
Fermentation
System
Fermentation Tank1200L/2400LPLC Stylebox2000*700*400
Yeast Tank20LEnergySteamed Boiler72-100kg/h
Bright Beer Tank
(optional)
2400lelectrical heating45kw
Pipeline&valvesaccessory

Trade Details

Description of goodsMicro brewery
Capacity100L-100HL
MaterialSUS304 or red copper
WarrantyThree years for main equipment
MOQ1set
Delivery time15-40 working days, based on the capacity
Supply abilityMore than 100pcs,based on the capacity
PackageSteel frame or wooden cases, according to your requirement
Payment termT/T,Escrow
Trade termFOB/EXW
Port of loadingQingdao



Why Choose Us



1. Compare to other suppliers, we promise to spend more times on the polish and treat for the welding seam and port.
2. High Quality fitting adopted to keep long time use.
3. Best Service. From the time customer release the order till customer get the products, we will provide on-time service, and willing to solve any problem at the first time.
4. The products has one year Warranty from the time when the customer received the tanks.
5. Customer special design is available.
If you are interestesd in our equipment, please choose us .
We will give you the best service,high quality and  the reasonable price.
Welcome you to visit our factory.
Waiting for your inquiry.
