High Quality High Speed Circuit Board Dry Laminating Machine

FOB Reference Price:Get Latest Price
$13,000.00 - $15,000.00 / Set | 1 Set/Sets circuit board laminating machine (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Case
Packaging Material:
Wood
Type:
Laminating Machine
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
FENGMING
Model Number:
YFMZ1100A
Power:
36kw
Voltage:
220/380V
Application:
Machinery & Hardware
Weight:
4600KG
Automatic Grade:
Automatic
Certification:
CE SGS ISO
Driven Type:
Mechanical
Dimension(L*W*H):
8100mm*1800mm*2000mm
Product name:
High Quality High Speed Circuit Board Dry Laminating Machine
Max.Laminating Width:
1050mm*1100mm
Min.Laminating Width:
300mm*350mm
Laminating Temperature:
≤130℃
Paper Thickness:
100-500g/
Laminating Speed:
0~90m/min
Diameter of Heating Roller:
351mm
Diameter of Film Paper core:
≤76mm(3 inch)
Mode of operation:
auto laminating machine
Function:
Wrapping Outer Paper
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
1000 Set/Sets per Quarter high speed dry laminating machine
Packaging & Delivery
Packaging Details
High Quality High Speed Circuit Board Dry Laminating Machine normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Port
NINGBO&SHANGHAI
Lead Time :
Shipped in 10 days after payment


 High Quality High Speed Circuit Board Dry Laminating Machine

Model

YFMZ1100A

YFMZ1200A

Max.laminating size(width × length)

1050mm×1100mm



1200mm×1300mm

Min.laminating size(width × length)

300mm×350mm

300mm×350mm

Laminating Speed

0~90m/min

0~90m/min

Paper Thickness

100-500g/m2

100-500g/m2

Power

36kw(normal is a half)

36kw(normal is a half)

Voltage

220/380V

220/380V

Diameter of Heating Roller

351mm

351mm

Diameter of Film Paper core

76mm(3 inch)

76mm(3 inch)

Weight:

4600KG

5300KG

Overall Dimension (L×W×H)

8100mm×1800mm×2000mm

8100mm×1900mm×2000mm
