High power wireless wifi CAN Bus converter gateway router Compatible SOCKET

Feedback Ratings
  • 1 Pieces
    US $188.00
  • 2-4 Pieces
    US $180.00
  • 5-9 Pieces
    US $167.00
  • >=10 Pieces
    US $156.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customization:
Customized logo (Min. Order:: 100 Pieces)
Customized packaging (Min. Order:: 100 Pieces)

More

Graphic customization (Min. Order:: 100 Pieces) Less
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Liaoning, China (Mainland)
Brand Name:
Guangcheng
Model Number:
GCAN-211
Support:
CAN2.0A and CAN2.0B
Baud rate:
5Kbps~1Mbps
2.4G WLAN interface:
support
Processor:
High speed 32-bit industrial grade processor
32 FIFO receiving buffers, maximum flow:
8000 FPS
Support protocol:
Ethernet, ARP, IP, ICMP, UDP, DHCP, DNS, TCP
Support AP and Station mode:
Yes
Electric isolation, insulation level:
DC 1500V
ESD Immunity level:
Contact Discharge±2KV, Air Discharge±15KV
Power supply:
DC+9~30V

Packaging & Delivery

Selling Units:
Single item
Single package size:
20.6X15.2X5.2 cm
Single gross weight:
0.4 kg
Package Type:
carton
Lead Time :
Quantity(Piece) 1 - 50 >50
Est. Time(day) 3 To be negotiated
Product Description

Introduction

The GCAN-211 is a CAN Bus converter, used for WiFi and CAN Bus connection. It is a high-performance CAN Bus converter, whose function is to realize interconnection easier and extends the application scope of CAN Bus.

Hardware Features

1. High speed 32-bit industrial grade processor
2. Embedded Watchdog timer
3. FLASH storage, can store parameters
4. External voltage (DC+9~30V), recommend voltage12V/24V
5. Current: 80mA, 24V DC
6. Electrostatic discharge (ESD) Immunity level: Contact Discharge±2KV, Air Discharge±15KV
7. Fast transient Burst Impedance Level: ±1KV
8. Surge immunity level: ±1KV
9. Working temperature: -40.00℃~ 85.00℃
10. Working humidity: 5%~95%, no condensation
11. Dimensions: 118mm (L) * 93mm (W) * 23mm (H)

CAN Features

1. Integrate two CAN-Bus channels, with terminal connection
2. Support CAN2.0A and CAN2.0B, conform to ISO/DIS11898
3. Support communication baud rate: 5Kbps~1Mbps
4. Electric isolation, insulation level: DC 1500V
5. 32 FIFO receiving buffers, maximum flow: 8000 FPS

Ethernet Features

1. Restore the network connection automatically after disconnecting, can establish a TCP connection.
2. SOCKET working mode compatibility (TCP Server, TCP Client, UDP, etc), program communication software according to standard SOCKET rules
3. Support protocol: Ethernet, ARP, IP, ICMP, UDP, DHCP, DNS, TCP
4. Support secondary development, we can provide VB routine

WiFi Features

1. Integrate 2.4G WLAN interface, conform standard IEEE802.11a/b/g
2. Support AP and Station mode

Detailed Images
Related Products
Certifications
Our Company

It is national certified high-tech enterprise. Our company has more 20 own intellectual-property rights with all of main products developed by ourselves, which is a leading supplier and service provider of industrial interconnection industry in China. We major in development, production, sales of industrial communication equipments and automatic equipments. The products cover CAN-Bus analyzer, ECU downloader, industrial gateway, remote IO, PLC core-board, and servo driver, software and hardware of industrial communication and providing for comprehensive solution. Since founded in 2010, our company has been on a mission to “promote the progress of industrial interconnection technique, offer competitive product and service”. We always create value for our customers. Now, we have served over 10 billion customers, involving traffic, electric power, energy, medical apparatus, ship, military industry, and automatic, multiple industries.

Our Service

1. Service: 1 years guarantee, and professional technical staff help.
2. Supply ability: We usually have 300-500 units in stock for urgent orders.
3. Capacity: 500/month, can meet the demand of most enterprises application.
4. Lifetime: At least 5 years for each device, can still produce just if you need.
5. Cooperation: Welcome the cooperation with distributors all over the world.

Packing & Delivery


Packing
1. Standard package. Carton
2. Customized design

Delivery Time
2~5 days after receipt of your payment

FAQ

1.How to make sure the quality?
A. Process Quality Control
B. Final Quality Control
C. Outgoing Quality Control
2. How to get the order?
First,Tell us the model and quantity of the products you want.
Second ,we will make a PI for you.
Third, After confirm everything,the payment will be arranged (Paypal, Western Union,T/T or Ali Trade Assurance for your money safety are welcomed)
Fourth, we will send you the goods within the promissory time.
3. What's the delivery time?
A. Sample within 2-5days;
B. Wholesales 4-7days according different quantities;
C. OEM 7-14 days after all info confirmed.
D. ODM depends on the detail requirements.
4. Can you do the design for us?
Yes, Just tell us your idea (logo,text., etc) and our professional R&D team will help to carry out your ideas into reality.
Your any requests would be much appreciated, so DO NOT hesitate to contact us

Packaging Details
