High pressure ash slurry pump and water usage fecal sewage

FOB Reference Price:Get Latest Price
US $375-980 / Units | 1 Unit/Units OEM/ODM (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
APK
Model Number:
WQ100-100-40-22-25c4
Theory:
Centrifugal Pump
Structure:
Single-stage Pump
Usage:
Water
Power:
Electric, 22kw/30hp
Standard or Nonstandard:
Standard
Fuel:
Other
Pressure:
Low Pressure
Application:
Sewage
Product name:
heavy duty large flow drainage wastwater sewage submersible pump
Flow:
100m3/h
Head:
40m
Material:
Cast iron/stainless steel
Outlet dia:
4"/100mm
Motor Sep:
3 phase/50Hz;420v OR negotation
Certificate:
ISO; CE;BV;TUV; etc
Warranty:
One Year OR negotation
OEM:
Accept
Supply Ability
Supply Ability:
10000 Unit/Units per Month
Packaging & Delivery
Packaging Details
heavy duty large flow drainage wastwater sewage submersible pump with Woodren package or 20'inch container
Port
Qingdao or any port in China
Lead Time :
2-5 working days
Product Description

High pressure ash slurry pump and water usage fecal sewage

Product details

Product nameheavy duty large flow drainage wastwater sewage submersible pump
Flow100m3/h
Head40m
Power22kw/30hp
MaterialCast iron/stainless steel
Outlet dia4"/100mm
Motor Sep3 phase/50Hz;420v OR negotation
CertificateISO; CE;BV;TUV; etc
WarrantyOne Year OR negotation
OEMAccept
Product Keywordshigh pressure ash slurry pump,high pressure and water usage slurry pump,high pressure and water usage fecal sewage pump






Your require :



Please confirm more details
we will sent you price list.

1. what the water pumps head
2. what the water pumps water capacity
3. any request about the outlet diameter     Send inquiry
4. how about the voltage, 380v or 220v(50Hz/60Hz)
5. what the material, cast iron or stainless steel





Products description :

Parameter range:

Flow range: 5-4500m3/h

Head range:5-200m                                                Send inquiry

Outlet dia : 25-600mm

Temperature: 0-40℃

The pumps is regular type as blow in our factory :

Model      Flow       Head  Power Outlet dia   Voltage    Speed
(m3/h) (m) (kw)(mm)(V)(r/min)
WQ50-8-25-2.28252.2503802900
WQ50-9-22-2.29222.250
WQ65-20-12-2.220122.265
WQ80-40-10-2.240102.280
WQ100-50-7-2.25072.2100
WQ40-10-35-31035340
WQ50-15-30-31530350
WQ65-37-13-33713365
WQ80-45-12-34512380
WQ100-60-9-36093100
WQ50-15-35-41535450
WQ65-20-25-42025465
WQ80-40-15-44015480
WQ100-60-12-460124100

WQ150-100-8-4

10084150
WQ50-20-40-5.520405.550
WQ65-25-35-5.525355.565
WQ80-30-30-5.530305.580
WQ100-65-18-5.565185.5100
WQ150-100-10-5.5100105.5150
WQ50-20-50-7.520507.550
WQ65-30-40-7.530407.565
WQ80-65-25-7.565257.580
WQ100-80-15-7.580157.5100
WQ150-100-15-7.5100157.5150

Note:

Material: cast iron, stainless steel (ss201/ss304/ss316/ss316L)

We can acccept the custozied and OEM. Please send inquiry to us, if you need catalog and price.



Features:

  • Single channel or double channel impeller

  • Titanium alloy mechanical sealing

  • More than 8000 hours of continuous operation

  • Can working with total head

  • Fixed auto-couple  and mobile installation

  • Non-clogging

 high pressure ash slurry pump





Application:

  • Mining use,raw water

  • Drainge silt of pool, agriculture irrigation

  • Municipal and industrial waste water

  • Power plant and urban sewage treatment

  • Construction drainge

  • Drainage wastewater with particles

  • Other industrial applications
