High quality Cutting diameter Hinge boring Forstner Drill Bit for Wood

FOB Reference Price:Get Latest Price
$0.50 - $5.00 / Piece | 50 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Samples:
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
TONGHUI
Model Number:
TH-FBH series
Name:
Forstner Bit
Application:
Hardwood, Soild wood, Chipboard, Plywood
Usage:
Drill hole
Size:
15-60mm
Length:
90mm and 120mm
Color:
Black and sliver
Packing:
Carton or as your request
Supply mode:
Factory direct supply
OEM:
Acceptable
Samples:
Available
Use:
Wood Drilling
Material:
High Carbon Steel
Type:
Reamer
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Outer package: Cartons Or Customized packing at your request.
Port
NINGBO/SHANGHAI
Lead Time :
2~15 working days after confirmed sample.
Product Description

High quality Cutting diameter Hinge boring Forstner Drill Bit for Wood

1, Adopt high class Alloy, 45# Steel as material, with features of Long lifespan and Stable performance .
2. Application: Used to drilling holes in Soild wood, Hard wood, Laminated board, Chipboard and Plywood, etc

Details:
Brand
TONGHUI
OEM
Size
φ15-60mm
Length
90mm and 120mm
Material
High carbon steel 45#
Application
Soild wood, Hard wood, Laminated board, Chipboard and Plywood
Place of Origin
Zhejiang, China (Mainland)
Delivery time
2~15 working days after confirmed sample
Packing
Outer package: Cartons

TH-FBH

TH-FBM


TH-FBL


Main Features

1) Made of premium 45# High Carbon Steel
2) Good heat resistance, long service life. Sharp cutting edge, Not easy to break
4) Advanced CNC grinding technology to reduce the cutting resistance and achieve fine surface without burr.
5) High performance-to-price ratio, high work efficiency.Remove the chips easily,high speed and less heat
6) Bore precise, flat-bottomed holes in soild wood,hard wood,laminated board,chipboard and plywood,etc

Specifications
MODEL NO.
SPEC.
DIA.(MM)
LENGTH(MM)
SHANK(MM)
TH-FBH01
φ15
15
90
8
TH-FBH02
φ16
16
90
8
TH-FBH03
φ18
18
90
8
TH-FBH04
φ19
19
90
8
TH-FBH05
φ20
20
90
8
TH-FBH06
φ22
22
90
8
TH-FBH07
φ25
25
90
8
TH-FBH08
φ26
26
90
8
TH-FBH09
φ28
28
90
8
TH-FBH10
φ30
30
90
8
TH-FBH11
φ32
32
90
10
TH-FBH12
φ35
35
90
10
TH-FBH13
φ38
38
90
10
TH-FBH14
φ40
40
90
10
TH-FBH15
φ42
42
90
10
TH-FBH16
φ45
45
90
10
TH-FBH17
φ48
48
90
10
TH-FBH18
φ50
50
90
10
TH-FBH19
φ53
53
90
10
TH-FBH20
φ55
55
90
10
TH-FBH21
φ60
60
90
10

High quality Cutting diameter Hinge boring Forstner Drill Bit for Wood

Forstner bits, named after their inventor, Benjamin Forstner, bore precise, flat-bottomed holes in wood, in any orientation with respect to the wood grain. They can cut on the edge of a block of wood, and can cut overlapping holes. Because of the flat bottom to the hole, they are useful for drilling through veneer already glued to add an inlay. They require great force to push them into the material, so are normally used in drill presses or lathes rather than in portable drills. Unlike most other types of drill bits, they are not practical to use as hand tools.

The bit includes a center point which guides it throughout the cut (and incidentally spoils the otherwise flat bottom of the hole). The cylindrical cutter around the perimeter shears the wood fibers at the edge of the bore, and also helps guide the bit into the material more precisely. The tool in the image has a total of two cutting edges in this cylinder. Forstner bits have radial cutting edges to plane off the material at the bottom of the hole. The bit in the image has two radial edges. Other designs may have more. Forstner bits have no mechanism to clear chips from the hole, and therefore must be pulled out periodically.

Sawtooth bits are also available, which include many more cutting edges to the cylinder. These cut faster, but produce a more ragged hole. They have advantages over Forstner bits when boring into end grain.

Bits are commonly available in sizes from 8–50 mm (0.3–2.0 in) diameter. Sawtooth bits are available up to 100 mm (4 in) diameter.Originally the Forstner bit was very successful with gunsmiths because of its ability to drill an exceedingly smooth-sided hole.

(from Wikipedia)

Related Products
Our Advantage

•Prompt Production & Delivery
•Available in Various Requires
•Customized Specifications Accepted
•OEM & ODM Service and Buyer Label Offered
•Quick Response to Your Inquiry on Line or Telephone

Packing & Delivery

Packing & Delivery

Outer package: Cartons Or Customized packing at your request.

Delivery time: 2~15 working days after confirmed sample.

FAQ

1. Q: Is OEM available?
A: Yes, OEM and customization are available. Also, we can provide label printing service.

2. Q: Are samples available?
A: Yes, but sample fee and freight fee will be required, the sample fee will be returned to you after you making official order.


3. Q: Is there cheap shipping cost to import to our country?
A: For small order, Express will be the first choice, And for bulk order, sea ship way is best but take longer time. For urgent orders, we suggest via air to airport or by Express.

4. Q: What is your payment terms?
A: T/T, L/C, WESTERN UNION and ONLINE TRADE ASSURANCE ORDER.

5. Q: What's your delivery time?
A: 2-15 working days after confirmed sample
