High quality hydraulic ram pumps for sale

FOB Reference Price:Get Latest Price
$150.00 - $1,500.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
BOSHENG
Model Number:
YCY14-1D
Structure:
Piston Pump
Usage:
Oil
Application:
The pressure source
Power:
Electric
Fuel:
antiwear hydraulic oil 46#(Chinese Industrial Standards)
Pressure:
31.5MPA
Material:
Cast Iron
Weight:
22~250 KG
Rated torque:
56.7~1906 Nm
Rated speed:
1000~1500
Preset pressure:
31.5MPA
Pump shaft output diameter:
20~60
Drive mode:
Electromotor
Motor power:
2.2~75KW
Installation method:
Double hole up and down connection or four hole standard connection
Tubing connection:
Threaded connection or flange connection
Standard or Nonstandard:
Standard
Theory:
piston motion
Supply Ability
Supply Ability:
800 Set/Sets per Month
Packaging & Delivery
Packaging Details
The carton / The partition box
Port
shanghai
Lead Time :
30 days after payment been done

High quality hydraulic ram pumps for sale

Product Description
Pump series specifications and technical parameters
Nominal displacement ml/r1.252.55102532406380160250400
Rated pressure (MPa)31.5
Theoretical displacement (ml/r)1.42.75.510.926.934.141.667.880.7165.1253.7365.3
Rated speed (r/min)15001000
Theoretical torque (Nm)7.314.729.356.7140177.7217354.2421861.91324.31906
Transmission power (KW)1.32.65.28.922.527.93655.672.193145.3232.4
Variable formYCY
MYCY
MCY
PCY
SCY
CCY   000000000
DCY
LCY   000000000
ZCY   000000000
BCY
Note: There is a "0" that the flow can be commutated, "√" means that the flow can not be reversed, the blank that no varieties

working principle
      The main part (see structure section) is driven by the drive shaft to rotate the cylinder so

that the seven plungers evenly distributed on the cylinder rotate around the drive shaft center-

line, and the shoe in the column slide assembly is pressed against the variable head Or swash

plate). In this way, the plunger with the rotation of the cylinder for reciprocating movement, to

complete the oil and oil pressure action.

Products applied to:

    Metallurgical machinery / forging equipment / shipbuilding / petrochemical industry / large

shiplock opening and closing system / vehicles and construction machinery.

Series of products

Company Information



Packaging & Shipping

FAQ

1.The pump can not afford to build pressure, insufficient flow?

Reduce the resistance loss in the suction passage, increase the level of the tank, disassemble

the oil pump, clean the moving parts, reassemble the equipment, and adjust the variable

characteristics of the pump.
2. Pump noise is too large?
Replace the oil at the working temperature or start the heating tank before starting. Reduce the

resistance of the intake passage and increase the oil level.
3. Oil and oil pump temperature rise is too high?
Replace the oil, increase the volume of the tank or increase the cooling device, repair the

relevant components; overhaul the oil pump.
4. The oil pump returns too much oil?
According to the "decoration" section of the maintenance of these two pairs of sports pay.
5. Leakage at the pump seal?
Dismantling the sealing parts, check the details of "0" ring and seal the damaged part and a

matching part of the scratch, bump, burrs, and grinding clean, replacing the Xinmi seal; replace

SD or SG shaped skeleton oil seal lips.
