Horizontal cylinder T611 boring machine price

  • 1 - 2 Sets
    $19,700.00
  • >=3 Sets
    $18,600.00
Model Number:
T611
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Table Travel (X) (mm):
1400 mm
Table Travel (Y) (mm):
1000 mm
Table Travel (Z) (mm):
650 mm
Number of Axes:
3
Max. Table Load(kg):
3000
Travel (W-axis) (mm):
300 mm
No. of Spindles:
4
Range of Spindle Speed(r.p.m):
530 r.p.m
Spindle Motor Power(kW):
7.5
Type:
Horizontal, Boring Mills
Condition:
New
CNC or Not:
Normal
Place of Origin:
Shandong, China
Brand Name:
WOJIE
Voltage:
380V/220V/480V
Dimension(L*W*H):
2700*1600*2100
Weight (T):
5 T
Certification:
CE ISO
Warranty:
2 years
After-sales Service Provided:
Online support, Video technical support, Free spare parts
Key Selling Points:
Multifunctional
After Warranty Service:
Video technical support, Online support, Spare parts
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Retail
Local Service Location:
Egypt, Canada, Turkey, Italy, France, Germany, Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Russia, Australia, Morocco, Chile, Algeria, Kazakhstan, Nigeria, Tajikistan
Showroom Location:
Egypt, Canada, Turkey, Italy, France, Germany, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Pakistan, Mexico, Chile, Uzbekistan, Tajikistan
Spindle bore:
85mm
Spindle taper:
Morse 5
Spindle speed:
25-530r/min
Worktable feed speed:
5-160mm/min
Name:
Line Boring Machine
Product type:
Portable Boring Machine
Product name:
Cylinder Boring Machine Motorcycle
Functions:
Broing
Usage:
Reboring Automobile Cylinders
Table Size (mm):
1130*930
Supply Ability
Supply Ability:
300 Set/Sets per Year
Packaging & Delivery
Packaging Details
The machine will be packed by the plywood case
Cylinder boring machine TX68 horizontal boring machine
Port
Qingdao or Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Product Description
Product main features and uses:
1. Appearance beautiful generous overall layout of the overall layout.
2. The machine body, the upright post and the sliding block are all made of rectangular guide rail, and the stability is good.
3. Guide rail to take automatic quenching, high wear resistance.
4. Digital synchronous display, intuitive and accurate, can improve the work efficiency.
5. After the tailstock is optional
Product application:
1. This machine is suitable for machining the parts of single piece or small batch production in the machine shop.
2. Drilling, boring and hinge hole can be carried out on the machine tool.
Specifications
Units
Units
T611
Max. load of worktable
kg
kg
3000
Spindle speed step
9 step
Spindle speed range
rpm
rpm
20-450
Longitudinal feed step
6 steps
Longitudinal and transverse feed range
mm/min
mm/min
6-250
Worktable rapid feed speed
mm/min
mm/min
2500
Headstock lifting and lowering feed speed
mm/min
mm/min
50-720
Spindle diameter
mm
mm
110
Quill travel
mm
mm
400
Table size
Mm2
Mm2
1130×930
Longitudinal travel of worktable
mm
mm
1400(without tailstock)
transverse travel of worktable
mm
mm
1000
Vertical travel of headstock
mm
mm
900
Spindle taper
MT6#
Spindle motor power
KW
KW
5.5/7.5
Longitudinal and transverse motor power
KW
KW
2.2
Headstock lifting and lowering motor power
KW
KW
1.5
Overall dimension
mm
mm
4800×2000×2500
Detailed Images
Related Products
Company Introduction
Packing&Shipping
FAQ
1. What is the payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;Irrevocable LC at sight .

2. What is your trade terms?
A : FOB, CFR and CIF all acceptable.

3.When is the delivery time?
A: If the machine you will order is standard machine, we can ready the machine within 15days.if some special machines will be some
longer.we will give you the answer accordingly.

4. What is your trade terms?
A : FOB, CFR,CIF or others terms are all acceptable.

5. What is your minimum order quantity and warranty?
A: MOQ is one set, and warranty is one year.but we will offer lifetime service for machine.

6. What is the package of the machines?
A: The machines standard will be packed in plywood case.
