Hot selling digital headend 256 ip to 8 qam modulator hd rf encoder for sale

  • 1-9 Pieces
  • 10-99 Pieces
  • >=100 Pieces
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 100 Pieces)


Graphic customization (Min. Order: 500 Pieces) Less
Contact Supplier
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Model Number:
IP Input
RF Output
IPTV Headend Systems
Product name:
Ip Qam Modulator
Product Keywords:
digital headend 256 ip to 8 qam modulator

Packaging & Delivery

Selling Units:
Single item
Single package size:
57X47X8 cm
Single gross weight:
5.0 kg
Lead Time :
Quantity(Piece) 1 - 10 11 - 100 >100
Est. Time(days) 3 15 To be negotiated
product discription

wolck  WK-3316 16 in 1 IP QAM DVB-C Modulator IP input and RF output

Product Description

16 in 1 IP QAM modulator is the latest generational Mux-scrambling-modulating all-in-one device . It has 16 multiplexing channels,

16 scrambling channels and 16 QAM (DVB-C) modulating channels, and supports maximum 512 IP input through the 3 GE ports and

16 non-adjacent carriers (50MHz~960MHz) output through the RF output interface. The device is also characterized with high integrated level,

high performance and low cost. This is very adaptable to newly generation CATV broadcasting system.

Key Features

*  3 GE ports (max 512 IP in):

    Data1 & Data2 bi-directional ports, max 512 IP in, 16 IP out

    Data port (located on front panel), max 128 IP in

*  Max 840Mbps for each GE input

*  Support accurate PCR adjusting

*  Support CA filtering, PID remapping and PSI/SI editing

*  Supports up to 180 PIDS remapping per channel

*  Support DVB general scrambling system (ETR289), simulcrypt standards ETSI 101 197 and  ETSI 103 197

*  Support 16 IP output through Data1 & Data2 over UDP/RTP/RTSP

*  16 non-adjacent QAM carriers output, compliant to DVB-C (EN 300 429) and ITU-T J.83 A/B

*  Support RS (204,188) encoding

*  Support Web-based Network management


Detailed Images


      Contact: Ms.Liwen  TEL: +86 18816793651

Company Information

Related Products





Packaging & Shipping


Standard export carton packing.


3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
