The MA5608T has a strong adaptability to the environment and can be deployed quickly. In FTTx networks, the OLT is moved closer to the user side, which can save backbone optical cable resources. This solves the problem of a few users, when FTTx services are applied in an area with a low population density.
MA5608T OLTDeployed at the remote end, including the base stations (BSs) and outdoor environments
2 U high, and MA5608T Device supports a maximum of two service boards
MA5608T MSAN Device Connected to ONUs or ONTs and used in FTTB/C and FTTH scenarios
MA5608T Connected to xDSL terminals and phones and used in the MSAN/DSLAM scenario
Dimensions (H x W x D)
442 mm × 244.5 mm × 88.1 mm
–40°C to 65°C 5% RH to 95% RH
Dual-power supply protection DC power supply: -38.4V to -72V AC power supply: 100V to 240V
Switching Capacity — Backplane Bus
16 x 10G GPON
48 x GPON
96 x P2P FE
96 x P2P GE
Upstream ports: 10 GE optical and GE optical/electrical ports Service ports: 10G GPON optical port, GPON optical port, P2P FE optical port, P2P GE optical port, and Ethernet optical port, ADSL2+ port, VDSL2 port, SHDSL port, POTS port, and ISDN port
Layer 2/Layer 3 line-rate forwarding
Static route, RIP, OSPF, and MPLS
Clock synchronization schemes: BITS, E1, STM-1, Ethernet clock synchronization, 1588v2, and 1PPS + ToD
GPON Maximum split ratio of 1:128
10G PON Maximum split ratio of 1:256
GPON Maximum logical distance between devices: 60 km
XG PON Maximum logical distance between devices: 100 km
