Industrial Ultrasonic Sewing Machine for Sportswear

FOB Reference Price:Get Latest Price
$900.00 - $1,500.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
CR-HM
Max. Sewing Speed:
0-20MM
Lead Time:
Quantity(Sets) 1 - 20 >20
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 3 Sets)
Customized packaging (Min. Order: 3 Sets)

More

Graphic customization (Min. Order: 3 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Max. Sewing Thickness:
500GSM
Overall Dimensions:
128*61*127CM
Power:
2000W
Warranty:
1 Year
After-sales Service Provided:
Video technical support, Online support, Free spare parts
Condition:
New
Type:
Industrial Sewing Machine
Brand Name:
CR
Stitch Formation:
Chain Stitch
Mechanical Configuration:
Flat-Bed
Stitch Length:
0-5MM
Feed Mechanism:
Manual
Certification:
CE
Keywords:
Industrial Ultrasonic Sewing Machine for Sportswear
Product name:
Industrial Ultrasonic Sewing Machine for Sportswear
Application:
sportswear ,non woven fabric sealing
Weight:
140KGS
Model:
CR-HM
Voltage:
220V
Output:
20Khz
Color:
White
NEEDLE TYPE:
Needle-free
Horn size:
70MM
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
Naked packing or ply wood case for Industrial Ultrasonic Sewing Machine for Sportswear
Port
Shanghai or Ningbo
Lead Time :
Quantity(Sets) 1 - 20 >20
Est. Time(days) 7 To be negotiated
Video Description
Product Description

 Industrial Ultrasonic  Sewing Machine for Sportswear



Feature of  Industrial Ultrasonic  Sewing Machine for Sportswear
1.Use ultrasonic energy to cut, weld, seal, seam, stitch.
2.Eliminating traditional needle and thread,reduce material cost and more high speed
3.No dissipated edge, wrinkle and shrinkage.
4.Continuous working for mass production
5.No smoke, spark and danger during operation
6.Easy operation realizes lowest labor cost;double motors structure
7.Accurate and durable alloy rollers are designed by computer aid made with sculptured molds.



Suitable material of Industrial Ultrasonic  Sewing Machine for Sportswear
Fabrics of synthetic composition over 65%, polyester, nylon, TC, sponge, non-woven fiber ,satin, Thermo-plastic films.and other synthetic fiber material





Technical Specification of Industrial Ultrasonic  Sewing Machine for Sportswear

ItemIndustrial Ultrasonic  Sewing Machine for Sportswear

Model

CR-HM

Power Source

220V

Input Power

2000W

Output Frequency

20KHZ

Working Speed

0-20M/minute

Roller Size

12MM
Diameter:Ø50MM

Dimension of packing

128CM *61CM*127CM

Net Weight

140KG

Working Temperature

-10℃-28℃

Pressure System

Air type or manual type
































Application of Industrial Ultrasonic  Sewing Machine for Sportswear


Packaging & Shipping

Our Services



1. One year quality warranty,i mean if some parts of the machine damaged of course not by person on purpose we could provide one to you for free.

2. We have after-sale service department, engineers are mean to solve all the problems for customers, either through skype/msn,phone,email or go to customer's factory.

3. Lifelong time problems inquiring regarding the machines we could help you out any time you contact us.



Company Information





FAQ

 1.Q: Are you trading company or manufacturer ?
A: Yes, We are factory, all machines are made by ourself and we can provide customize service according to your requirement.

2.Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-30 days if the goods are not in stock, it is according to detailed request.

3.Q: Do you accept special design?
A: Yes,we accept design and manufacture products according to client's special requirements

4.Q: What about your warranty?
A: Our warranty is 1 year, all machine part can be replaced for free within 1year if broken(not including man made)

5.Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment
