Industrial commercial automatic canning machine equipment for sale and rotary soda drink make filler and seamer line for can

  • 1 Sets
    $50,000.00
  • >=2 Sets
    $15,000.00
Power:
3 kw
Model Number:
DGF 20-4
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
45 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 year, 1 year
Packaging Type:
Case
Packaging Material:
Wood
Type:
Filling Machine
Condition:
New
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Place of Origin:
China
Brand Name:
Higee
Voltage:
380 v 50 hz 3 phase
Application:
Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware, Apparel, Textiles
Weight:
3000 kg, 3000 kg
Automatic Grade:
Automatic
Certification:
CE, ISO 9001
Driven Type:
Electric
Dimension(L*W*H):
2450 * 2000 * 2100 mm
Name:
canned beverage production line
Model:
DGF 20-4
Filling head:
20
Capping head:
4
Filling speed:
5000 cph
Can capacity:
330 ml , 500 ml ,750 ml ,1000 ml
Bottle type:
cans , glass bottle , PET
Material:
SS 304
Product Certification certification
CE Certified.
Valid from 2018-01-18 until 2023-01-17

Packaging & Delivery

Selling Units:
Single item
Single package size:
2250X1780X2150 cm
Single gross weight:
3500.000 kg
Package Type:
Wood case for can filler and seamer machine
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 To be negotiated



Industrial commerial automatic canning machine equipment for sale and rotary soda drink make filler and seamer line for can



Can beer machine :













Application


This filling machine is based on the introduction of Germany 0+H technology, to produce a new type of beer or gas-filled drink filling machine, It is suitable for filling various types of cans (seamless tin and opentop), the equipment has a canister machine, its matching type depends on the production capacity.
The number of 20-157 indicated in the Filling valve head is 20, and the pitch is 157mm. The machine is supported by the base bolt to keep the ground clean, with simple adjustable foot bolts (adjustable range ± 50mm), the conveyor belt is at a specified height with a range of 1250-1400mm.

2, Main performance parameters and application range of filling machine

2.1 Production capacity and number of heads

Production capacity: 5000 Cans/hour (can be customized )

Filling valve head: 6 units

Sealing head: 1 units

2.2 Filling conditions

Filling temperature: 2-4℃
Filling type: Balanced pressure type
Filling mode: Use for isobar filling

2.3 Main dimensions:
Diameter of filling valve center: Ø1000

Enter the pitch circle diameter of the star wheel of the cans: Ø200

The Delivery height of the cans cover: minimum1250mm, maximum1400mm ( adjustment range: ±50mm )
Equipment external dimensions: L*W*H 2200*1720*2150 mm
Equipment net weight:~ 2000Kg

2.4 Range of application

(1)Beverage variety:Beer, Carbonated drinks and fruit juice drinks

(2)Can-type: All kinds of seamless tin and opentop

The diameter of the can:53-66mm

The height of the can:70-175mm

(3)Maximum production capacity of filling and sealing machine:200 cph per minute .



Glass bottles



Packaging & Shipping

FAQ

Are you a trading company or a manufactory?



1: We are a manufactory, we supply the factory price with good quality, welcome to visit our factory.



What’s your guarantee or the warranty of the quality if we buy your machines?



2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.



When can I get my machine after I paid?



3: The delivet time is based on the exact machine you confirmed.



How can I install my machine when it arrives?



4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.



How about the spare parts?



5: After we deal down all the things , we will offer you a spare parts list for your reference.
