LS VISION Shenzhen H.265 Cmos 4MP IR Night Vision Security Surveillance Vandal-proof Onvif POE Audio Bus 4 MP HD Dome IP Camera

  • 5-49 Pieces
    $35.68
  • 50-99 Pieces
    $34.58
  • >=100 Pieces
    $33.48
Resolution:
2592 x 1520
Type:
IP Camera
Style:
Dome Camera
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
8 day(s) after payment received
Customization:
Customized logo (Min. Order: 50 Pieces)
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
LS VISION
Model Number:
LS-ND7402D
Sensor:
CMOS
Special Features:
Vandal-proof
Key Feature1:
AUTO, 1/25s ~ 1/100000s
Key Feature2:
0.1Lux@ F1.2(AGC ON), 0Lux IR on
Key Feature3:
Infrared, POE, waterproof; Optional Audio
Image Sensor:
1/3" OV4689 CMOS
Embedded Solution:
MSC316DM
Video Standard:
H.265/H.264
Video Bitrates:
32Kbps - 8Mbps, VBR/CBR
Focal length:
3.6mm fixed lens
Media:
CMS, Android, IOS
Network Port:
1-RJ45, 100Mbps, POE

Packaging & Delivery

Selling Units:
Single item
Single package size:
16X16X13 cm
Single gross weight:
0.750 kg
Package Type:
Neutral Package
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 20 21 - 100 101 - 300 >300
Est. Time(days) 8 12 25 To be negotiated
Video Description
More Recommendation
Product Description

LSVISION Shenzhen 4MP Night Vision IP IR Security Surveillance Dome Camera


Key Features for 4MP IP dome camera:


1.1/3" UHD CMOS sensor

2.Max. 4MP resolution 2592 x 1520

3.low illumination 0.1Lux

4.Day/Night (ICR), AWB, 2D/3D-DNR, IR-CUT

5.D-WDR, Motion Detection, Privacy Mask, Mirror, rotate

6.RTSP and Onvif 2.6 compatible

7.H.265/H.264 dual-stream media server

8.Easy-to-use P2P Cloud service

9.Multi web browser, PC Client, mobile APP remote access

10.Optional customization Lens/Audio/ POE, etc.

11.Lightning protection 4000V

12.Strong water-proof housing, IP66


Specification
Product Name
LS-ND7402D 4mp IP dome camera
Image Sensor
1/3" OV4689 CMOS Sensor
Effective Pixels
2592(H)×1520 (V)
Electronic Shutter
AUTO, 1/25s ~ 1/100000s
Min. Illumination
0.1Lux@ F1.2(AGC ON), 0Lux IR on
Day/Night
Auto/Color/(B/W)/Timing
WDR
Digital WDR
White Balance
Auto
AGC/BLC
Support
DNR
2D/3D DNR
Other
Multi-lines OSD, Motion Detection, Privacy Mask, Mirror, Rotate
Embedded Solution
MSC316DM
Video Standard
H.265/H.264
Video Resolution
Main Stream:

20fps@4MP(2592x1520),25fps@3MP/1080P/720P

Sub Stream: VGA(640x480)/360P/QVGA@25fps, etc.
Video Bitrates
32Kbps - 8Mbps, VBR/CBR
Audio Standard
G.711-u/G.711-a, built-in microphone
IR Led
12 pcs IR Leds
IR Distance
15 Meters
Focal length
3.6mm fixed lens
Protocol
HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.
P2P
Yes
Web
IE , Firefox, etc.
Media
CMS, Android, IOS
ONVIF
2.6 compatible
Network Port
1-RJ45, 100Mbps, POE optional
Power Supply
12 VDC ± 10%
Power Consumption
< 5 W
Operating Temp.
-20℃-(+60)℃, 10%-90%RH
Certification
