Frequency range: 400 ~ 480MHz Number of channels: 16.Dimensions: 128*55*28mmWeight: 130.2gChannel spacing: 12.5KHz/25KHz.Working voltage: Rated DC3.7V.Battery capacity: 2500mAh (lithium battery).Environmental indicatorsWorking temperature: -20°C~+60°CStorage temperature: -20°C ~ +70°C
Receiver sensitivity: ≤0.25μV Adjacent channel selectivity: ≥60dBBlocking: ≥80dBRated audio distortion: ≤5%Receive Audio Power:0.5WSignal to Noise Ratio:25k≥45dB12.5k≥40dBTransmit power: 1.8w ±0.2w
Modulation method: 16kφF3E/8kφF3EModulation limit: ±5kHz/±2.5kHzAudio distortion: ≤5%Residual FM: -45dBAdjacent channel power:-67dBRadiated Emission:-36dBmShock and vibration:According GJB 150-2009 and MIL-STD-810 C/D/E/F/G standard.
The above specifications are tested in accordance with the TIA/EIA-603 standard. Due to the continuous updating of the technology, the above indicator data will be changed without notice.
