LifePo4 Battery system low frequency isolation transformer hybrid inverter (40kw)

$7,900.00 / Piece | 1 Piece (Min. Order)
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
BANGZHAO OR OEM
Model Number:
BZP-40KW
Size:
650x750x1100mm
Weight:
400KG
Input Voltage:
360V
Output Type:
TRIPLE
Type:
DC/AC Inverters
Output Power:
1 - 200KW
Output Voltage:
can be customized
Output Frequency:
50 or 60 HZ
Output Current:
182A
RS232 or 485:
optional
two start model:
Step Down Voltage Start and Variable Frequency Start
output wave form:
pure sine wave
type:
dc to ac
Voltage and frequency:
can be set
waterproof:
IP45 optional

Packaging & Delivery

Selling Units:
Single item
Single package size:
65X75X110 cm
Single gross weight:
380.0 kg
Package Type:
Honeycomb box with LifePo4 Battery system low frequency isolation transformer hybrid inverter (40kw)
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 1 >1
Est. Time(days) 10 To be negotiated

LifePo4 Battery system low frequency isolation transformer hybrid inverter (40kw)

Product Description

 -



Technical Features for LifePo4 Battery system low frequency isolation transformer hybrid inverter (40kw)

1, Two kinds of start mode: Reduction Voltage Start and Variable Frequency Start. Customers can set start mode according to the type of the load.

2, The output frequency can be set, this function is very convenient for customer.

3, The output voltage can be set between +20 % to -40 % of rated voltage. It’s a great convenience to users.

4, The DC input voltage range can also be set. Over-voltage point, under-voltage point, over-voltage recovery point, under-voltage recovery point all can be set via the LCD panel. Convenient for increasing or reducing the quantity of batteries, photovoltaic modules also can be used flexibly.

5, Pure sine wave output. with good transient response less than 40MS, little harmonic distortion, higher conversion efficiency and stable output voltage.

6, Powerful data display and fault instruction function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, output power KWH, time and date, temperature, fault code display.

7, Using the sixth generation efficient IPM intelligent module from Japanese Mitsubishi, high efficiency and stable performance. It with powerful protection function, the protection for short circuit, over load, over temperature is more safe and reliable. It’s service life can up to 15 years or more.

8, Wide input voltage can be set according to customer’s requirement. Input voltage range can be selected from 100-400V or 480-850V.

9, Product have passed the European CE (EMC and LVD) certificated and accredited by Australia CEC energy network.

 off grid

Technical Data for  LifePo4 Battery system low frequency isolation transformer hybrid inverter (40kw)



Model

BZP-30KW

BZP-40KW

Isolation mode

Low Frequency Transformer

DC Input

Rated voltage (Vdc)

240V

300V

360V

Rated current(A)

125A

100A

111A

AC Output

Rated output power

30KW

40KW

Output waveform

Pure Sine Wave

Rated Voltage

220V±3%

380VAC±3%

220V±3%

380VAC±3%

Phases

Single phase

3 phase 4 wire

Single phase

3 phase 4 wire

Rated current(A)

136A

45.5A (phase current)

182A

61A (phase current)

Frequency

50Hz or 60Hz

Rated output voltage range (V)

220/230/240/380/400/415VAC optional

Power Factor(PF)

0.9

Overload Ability

150%, 5 seconds

Efficiency

>93%

Waveform distortion rate (THD)

<3%(Linear load)

DynamicResponse(0 to 100% load)

5%,≤50ms

Display

LCD

Running mode

Working continuously

Electrical insulation properties

2000Vac, 1 Minute

Protection Function

Protection

Input reverse polarity, under voltage, overvoltage, output over-current, short circuit, overheating etc.

Cooling method

Fan-cooled

Short-circuit protection

Noautomatic recovery, need to restart the machine

Working environment

Noise ( 1 meter)

≤50dB

Degree of protection

IP20(indoor)/IP45(outdoor)

Working Altitude(m)

≤2000

Working temperature

-25~+55

relative humidity

0~90%,non-condensing

Mechanical dimension

Depth* Width * Height

650x750x1100mm

Weight (Kg)

260Kg

350Kg



Above parameter only for reference ,could be custom made to user specifications.

For LifePO4 battery system inverter:




IP45 outdoor type inverter optional:





5 battery cabinet.JPG



IP20 indoor type:

DSC_0075



Certifications

.jpg



Installation Case

-1



Company Information




FAQ



--1

Q 1. What's the payment term?



A. We accept TT,Western Union,Paypal,MoneyGram.







Q 2.How's the delivery time ?



A. Is due to order quantity, usually it will take about 3-7days for sample production,



Q 3.Tell me the standard of package?



A. For the small capacity, it use carton, but for big capacity, we should use honeycomb carton and pallet or  wooden case for protection.







Q 4.Would you accept to use our logo ?



A.It's no problem to do OEM.



Q 5.We want to know month capacity.



A. It depends on which model.For example for relay type small capacity , month capacity can reach near 2000pcs  and big capacity near 500pcs.



Q 6.Where is your market?



A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.



Q 7. What kind of certificate you have ?



A. Our company already achieve ISO9001, and for products, we have CE, SAA, G83 G59 etc .







Q8. What is the warranty period ?



A. Normally 1 year ,if order quantity enough can be extended to 3 years.
