Liugong CLG835 3ton Wheel Loader

$32,000.00 / Unit | 1 Unit (Min. Order)
Rated Load:
3ton
Model Number:
CLG835
$32,000.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Dimension(Long * Breadth * High):
8185*3000*3465MM
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
LIUGONG
Certification:
CE ISO
Type:
Front Loader
Moving Type:
Wheel Loader
After-sales Service Provided:
Engineers available to service machinery overseas
product name:
Liugong CLG835 Small Wheel Loader Price
Color:
Optional
RATED POWER:
92KW
Bucket capacity:
1.5m3
Operating weight:
10900kg
Max. breakout force:
90kn
Max. dump clearance:
3160mm

Packaging & Delivery

Selling Units:
Single item
Single package size:
1X1X1 cm
Single gross weight:
10000.0 kg
Package Type:
nude package
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 15 To be negotiated

Liugong CLG835 3ton Wheel Loader



Rated load

3000Kg

Operating weight

10200Kg

Rated bucket capacity

1.7m3

Max. breakout force

90kN

Max. dump clearance

3160mm

Dump reach

1050mm

Dump angle at any position

≥45°

Digging depth(with bucket bottom horizontal)

212mm


Min. turning radius


-----Outside of bucket

5600mm

-----Outside of rear wheel

5205mm

Oscillating angle of rear axle

±11°

Lifting time of bucket

≤5.8s

Lowering time of bucket

≤3.77s

Dumping time

≤1.43s


Working Equipment


Model of oil pump

CBGj2100

System pressure

16Mpa

Model of multi-way directional valve

DF25.2C

Pilot valve

DJS2-UX/UU


Axle And Tyre


Type of main reducer

Spiral bevel gear, single stage

Gear ratio of main reducer

5.286

Type of final reducer

Single stage planetary

Gear ratio of final reducer

4.75

total ratio

25.1

Max. tractive force

93.5kN

Tyre size

17.5-25


Transmission System


Torque Converter

Type

3-elements,single stage(Shantui)

Torque ratio

3.1

Cooling type

Pressure oil circulating

Gear box

Type

Power shift(China advance)

Gear shifts(Forward/Reverse)

F4/R2

Traveling speed(Km/h)

Forward/Reverse

7.7/9.5

Forward/Reverse

13/18

Forward

25

Forward

40


Braking System


Service brake

Air over oil activate 4 wheel brake with capliar disc brake

Air pressure

0.68Mpa

Parking brake

Draper -type soft axle control


Steering System


Type

Middle articulated frame. Co-axis flow amp.steering

Model of steering pump

CBGj2050

Model of redirector

BZZ5-E400C

System pressure

14MPa

Articulated steering angle

38±1°(L/R)


Dimensions


Length(with bucket on ground)

7135mm

Width(to outside of wheels)

2350mm

Height(To the top of the cab)

3300mm

Bucket width

2440mm

Wheel base

2750mm

Tread

2050mm

Ground clearance

395mm


Service Capacities


Fuel tank

140L











Packaging & Shipping
