Low Cost 4CH HD SD Card WiFi 3G 4G Mobile DVR

FOB Reference Price:Get Latest Price
$20.00 - $21.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
woshijia
Model Number:
IL-AHD2008N
Name:
Low Cost 4CH HD SD Card WiFi 3G 4G Mobile DVR
RS485 PTZ/Wifi/3G::
Support
Type::
4*720P AHD DVR
HDD::
1 X SATA (Up to 4TB)
Playback::
4*720P realtime
Digital Input::
4ch 1080P/8ch D1
Audio In/Out::
1CH Audio in/1 CH Audio out
Supply Ability
Supply Ability:
3000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
special export box
Port
Shenzhen

 Low Cost 4CH HD SD Card WiFi 3G 4G Mobile DVR

Physical Parameter





*. Chip:  HI3520D

  Video input: 8*BNC

Video output: 1*VGA/1*HDMI

Alarm In/Out: NO

Audio In/Out: NO/1ch

USB Port: 2*USB Port





Main features

1.Video input: AHD DVR: 8CH*960P@25fps
2.Encode config: 1080P/720P/960H/D1
3.1ch 720P realtime playback, support 1 SATA HDD (MAX 6TB )
4.RS485: Yes (PTZ: Support )
5.3G/WIFI: not support





  Other Character

*. View: PC(CMS and IE:DDNS /Cloud),Mobile

*. Max Support :16*720P

*. IOS ,Android support

*. Mobile app:HDEYE

*. H.264 Compression

*. P2P ,cloud support

*. Free CMS

*.  Cloud: xmeye.net





  Package



 IL- AHD2008N

1*User manual

1*Adaptor(12V ,2A )

1*Mouse

Unit size :   200mm*210mm*45mm

Pack Size:  290mm* 260mm* 80mm

Weight:2KG





System

Main processor

   HI3521

Video

video compression

H.264(High Profile);

Encode

5M/3M/1080P

Decode

5M/3M/1080P

Multi-mode

input

168CH*720P@25fps/ 8CH*720P+4CH*960H / 16CH*960H

Audio

Audio compression

G.711A

Intercom

support

Recording and Playback

Record mode

Manual>alarm>motion detection>timing

Playback

2ch 1080P  playback

Storage and backup

Space occupation

960H:12~20G/ day*channel

720P:20G~30G/ day*channel

audio:691.2M/ day*channel

Backup mode

Network backup,USB HDD, USB writer

Interface

Video input

  1*WLAN Port

Video output

1*HDMI

Audio input

1ch RCA

Audio output

1ch RCA

Alarm input

NO

Alarm output

NO

Network interface

RJ45 10M/100M Adaptive Ethernet port

PTZ control

One RS485;support multiple PTZ protocols

USB

2 USB ports

Hard disk

1 X SATA (Up to 6TB)

Wireless

NO

Other

Power

12V2A

dimension



  255mm*218mm*43mm



Skype: sectecsales36


Detailed Images





Company Information







Other style DVR needed, email me to send u catelogue





Skype: sectecsales28
