Low price electric car hub motor 15kw driving kit with CE

FOB Reference Price:Get Latest Price
US $890-2,999 / Piece | 1 Set/Sets (Min. Order)
Supply Ability:
4000 Set/Sets per Month
Port:
Shunde Foshan
Overview
Quick Details
Brand Name:
GA
Model Number:
GA15KW
Type:
Asynchronous Motor
Frequency:
112
Output Power:
168
Protect Feature:
Waterproof
Phase:
Three-phase
Certification:
CE
AC Voltage:
Other
Place of Origin:
Guangdong, China (Mainland)
Efficiency:
IE 3
Power:
15kw
Battery voltage:
168V DC
Max output Current:
280A
Ratio:
16.9 /12.3/16.2 /17.8/10.6 /8/9/6.5
Motor max. speed:
7000RPM
Max Capacity:
45KVA
Rated speed:
2800rpm/3400rpm/4500rpm
Brake:
hydraulic/mechanics
Communication mode:
CAN
Motor max torque:
150N.m
Packaging & Delivery
Packaging Details
Standard seaworthy packing
Delivery Time
15 days for standard products per payment

Leader of the one stop driving system solution provider appreciates your interest. Definitely, we will endorse your trust and will deliver the best performed product and service for our esteemed customer.



We develop and sell driving kit including motor, controller, and axle for our customers for 40 plus countries and regions all over the world. Meanwhile, we are pleased as well to provide the optional parts, such as charger, dashboard, DC-DC converter, steering system, suspension,chassis, tires, and battery pack per request on your behalf.







Typical Electric Vehicle Performance


GEV15001





Maximum Speed60km/hVehicle size(L*W*H)5500*1810*2250mm
Endurance mileage100kmSeats23
Unloading weight2000kgWheelbase3400mm
Full loading weight3840kgFront wheel tread1420mm
Maximum slope20%Rear wheel tread1440mm
Noise<50dBTires145/70R12, 4pcs
BatteryLithium batteryDriving system168V 15kw





 GEV1502



Maximum Speed100km/hVehicle size(L*W*H)3741*1475*1870 mm
Endurance mileage100kmSeats7
Unloading weight1200kgWheelbase2450mm
Full loading weight1800kgFront wheel tread1280mm
Maximum slope20%Rear wheel tread1280mm
Noise<50dBTires165/65R13, 4pcs
BatteryLithium batteryDriving system168V 15kw





Driving System

Item SpecificationPicture
MotorRated Power15kw
Peak Power30kw
Rated Torque43n.m
Peak Torque150n.m
Max Working Speed7000RPM
Insulation ClassH
Protection gradeIP55
Coolingair
Protection ClassIP66
Dimensionφ230×304mm
Installation sizeTailor made to
customer's size
weight48kg

Controller assembly

Including controller

key switch

stall switch

accelerator

wire harness

Rated Input Voltage (battery  voltage)168V
Auxiliary power12V
Max output Current280A
Rated Capacity25KVA
Max Capacity45KVA
Analog input2
Cooling Forced air cooling
Protection Class IP66
Controller Case PC40
Dimension 270x238x180
Size(L*W*H)328*253*113mm
weight9.5kg
Rear axleRatio16.9 /12.3/16.2 /17.8/10.6 /8/9/6.5
Center distance 72mm
Speed capacity 8000RPM
Torque capacity 200N.m
Noise 65dB
LengthTailor made to
customer's size
Installation size
Leaf spring distance
Brake style
Hub  size
Est. net weight70kg
PackingWooden box
HS code87085079





 Optional Parts



Item Spcificatioin Picture
DC  Converter
(GA-ZHQ-1)
Input voltage (V)168
Output voltage(V)12
Protection class IP68
Output current20A/30A
HS code85044099
Charger
(GA-CDJ-1)
Input voltage (V) 220/110
Battery voltage (V)168
Charging current (A)25/30/35
HS code85044099
Dashboard
(GA-YB-1)
Output voltage(V)12
DisplayInstantaneous current
Speed
Battery power
HS code90329000

Steering  system

(GA-FX-1)

IncludeSteering wheel
Light control
Horn switch
Handbrake
HS code87089490
Battery pack
(GA-DC-1)
voltage(V)6/8/12
Battery capacity(Ah)175
Size(mm)300*180*180
Weight(Kg)40
HS code85072000
Suspension system
(GA-XG-1)
Include Shock absorber spring
Front wheel /mouting hub
Front wheel / mounting frame
HS code87088010
Tires
(GA-LT-1)
Size 185/60R14
195/65R15
205/55R16
215/45R17
HS code40112000







Norms and Practice



To improve efficiency and maintain both parties' mutual benefit, you are kindly to read the following norms and practice, which is the integrated part of the agreement we are going to reach.
1Delivery time for standard parts is within 20 days.
2Warranty of driving system is one year. Any damage of the parts by violating the instructions does not belong to the warranty coverage.
3Payment for MOQ (5 sets)is 100% lump-sum before  production, payment beyond MOQ is 30% for prepaid, and balance paid before sihpment.
4The actual parts and accessories might be not the same due to the shape of the vehicle, purchased items, country norms, and applicability.
5Not to be reprinted, translated or otherwise reproduced in whole or in part without written permission from Foshan Shunde Green Motor Technology Co., Ltd. All rights reserved.
6Should you ever require assistance or any complaints, all you need to do is to contact our president & global chief service officer (GCSO),reach his mobile phone at +86 13702349858.
7For more details of our company, please visit http://www.greenmotortech.com. Green Motor Technology Co. wish you a safe and pleasant driving trip.



Board of Director’s Message



First thank you for your interest of our products and service. The Green Motor Technology Co.(GA) is an innovative technology company that specializes in developing and manufacturing driving systems for electric vehicles (EV). With two decades plus years of expertise and leadership in the dynamic driving system, GA’s AC driving system serves our customers for more than 35 countries and beyond, particularly, some customers won championship in their national competiton by adopting our driving system, and we have earned more and more repeated business partners by providing consistent products and shared value with customers.Sincerely I wish you have a pleasant experience with us and please feel free to let us know your concerns.





Rewards, Certificates, and customer reference



Customer from Sri Lanka won the first prize over national EV race by adopting GA’s driving system.



Glimpse of business partnership from US, Germany, Britain, France, Belgium, Spain, Turkey, Slovakia, Brazil, Australia, Korea, India, Thailand, Sri Lanka, and Mozambique.   .







  Factory Corner








  Packing



The reason why you choose us?

  1. Attractive price versus superior quality product.
  2. Tailor made to the customer’s size.
  3. On time delivery.
  4. Team commitment, reliable partnership.
  5. Customer focused & market driven.
