MAL 20mm Bore 25-500 Stoke Single Rod Double Action Aluminum Alloy Small Spring Pneumatic Air Cylinder

$1.00 - $8.50 / Unit | 1 Unit (Min. Order)
Maximum Stroke:
500mm
Shaft Diameter:
20mm or custom
Model Number:
MAL20-25
$3.40
- +
available
MAL20-50
$3.50
- +
available
MAL20-75
$3.90
- +
available
All 14 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Units)
Customized packaging (Min. Order: 1 Units)

More

Graphic customization (Min. Order: 1 Units) Less
Samples: $4.00 /Unit, 1 Unit (Min. Order): Buy Samples
Contact Supplier
Samples - $4.00 /Unit, 1 Unit (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 YEAR
Applicable Industries:
Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
After Warranty Service:
Online support
Local Service Location:
None
Showroom Location:
None
Standard or Nonstandard:
Standard, standard
Structure:
General Cylinder
Power:
Pneumatic
Body Material:
Aluminum
Place of Origin:
Shanghai, China
Brand Name:
Yolon
Product name:
mini cylinder
Material:
Stainless Steel
Certificate:
ISO9001
Operating Pressure:
1.05Mpa
Packing:
Carton
Working medium:
Air
Application:
Automatic Control
Port size:
16/20/25/32/40

Packaging & Delivery

Selling Units:
Single item
Single package size:
20X10X25 cm
Single gross weight:
0.500 kg
Package Type:
one item one carton for MAL 20mm mini cylinder
Lead Time :
Quantity(Units) 1 - 1000 >1000
Est. Time(days) 7 To be negotiated
Video Description
Product Description
Bore size (mm)
20
25
32
40
50
63
Acting type
MSAL,MTAL
Single acting
-
MAL,MALD,MALJ
Double acting
MALC,MALCD,MALCJ
Double acting with cushion
Fluid
Air(to be filtered by 40 μm filter element)
operating presure
Double acting
0.1~1.0Mpa(15~145psi)(1.0~10.0bar)
Single acting
0.2~1.0Mpa(28~145psi)(2.0~10.0bar)
-
Proof pressure
1.5Mpa(215psi)(15bar)
Temperture
(-20~70)
Speed range mm/s
Double acting:30~800 Single acting:50~800
Stroke tolerance
0~150(0~+1.0)>150(0~+1.5)
Cushion type
MALC,MXLCD,MALCJ:Adjustable cushion;others:Bumper
Port size
1/8"
1/4"

MAL-CA
