Attributes
2000×4000Working Table Size(mm)
CNC Routermachine type
CNCcnc or not
Shandong, Chinaplace of origin
AC380V(Option)/50HZ/3PHvoltage
3Power (kW)
weight (kg):2100
warranty:1 Year
range of spindle speed(r.p.m):1 - 24000 rpm
positioning accuracy (mm):0.05 mm
number of axes:3
No. of Spindles:Single
travel (x axis)(mm):2000 mm
travel (y axis)(mm):4000 mm
repeatability (x/y/z) (mm):0.05 mm
Spindle Motor Power (kw):7.5kw
brand name:MISSILE
key selling points:Multifunctional
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor, Pump, Spindle, Control system, Gear rack, Ball screw, Square rail, Drive system, Reducer, Inverter, Vacuum pump, Lubrication system, Tool sensor
Traveling positioning accuracy:0.05mm
Repositioning accuracy:0.05mm
Max.traveling speed:50000mm/min
Max.working speed:20000mm/min
Spindle power:7.5kw
Drive&Motor:YASKAWA servo
Tool storage capacity:AC380V
Tool sensor:1
Lubrication system:1
Vacuum pump:Air type pump
Packaging Details:Wooden package
Port of dispatch:Qingdao port
Selling Units:Single item
Supply Ability:50 sets per Month cnc metal engraving machine
