Mobile Gold Mining Equipment Separator Machine Gold Trommel Scrubber for Small Scale Alluvial Gold Process

  • 1 - 2 Sets
    $35,000.00
  • >=3 Sets
    $8,000.00
Model Number:
JXSC-600
Power(W):
5kw
Lead Time:
Quantity(Sets) 1 - 2 >2
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
OEM SERVICE (Min. Order: 1 Sets)
Samples:
$35,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 year
After-sales Service Provided:
Video technical support, Online support, Field installation, commissioning and training, Field maintenance and repair service
Place of Origin:
Jiangxi, China
Brand Name:
JXSC or customerized
Voltage:
380v
Weight:
depends on final order
Certification:
BV, CE, SGS
Type:
Gravity Separator
Condition:
New
Production Capacity:
98%
Dimension(L*W*H):
customized
Applicable Industries:
Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining
Screen Size:
0-25mm
Rotation Speed:
27.6r/min
Feeding size:
0-80mm
Angle of inclination:
=<10°
Capacity:
20tph
Power:
5kw
Style:
Mobile or fixed
Application:
suitable to wash and sieve all kinds of material that with sticky clay
Motor:
electric or Diesel
Keywords:
Gold Trommel Scrubber
Supply Ability
Supply Ability:
500 Set/Sets per Month Gold Trommel Scrubber
Packaging & Delivery
Packaging Details
1. Standard parts packed in the wooden cases.
2.Big parts packed by plastic membrane.
3.The whole machine is loaded in the container.
Port
Xiamen/ Guangzhou/ Shenzhen/ Shanghai/ Qingdao port or as request
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 2 >2
Est. Time(days) 15 To be negotiated
Video Description
Trommel Scrubber

Trommel Scrubber Washing Machine Introduction

Trommel Scrubber is a main washing equipment in mining industrial, widely used for washing alluvial type/sand type ores and stones, which with much sticky clay, with much good washing effect for clay.

This machine with two parts: drum scrubber and screen. The drum scrubber is for washing ore, screen is for sieving different size particles after washing.

Washing Trommel Scrubber Screen Material

1. Manganese steel: normal material, not easy to replace, 2-3 monthes life time.
2. PU material: wear-resistance, long life time 4-6 monthes, corrosion resistant, splicing technology, replacable, very easy to replace.
3. Stainless steel material : wear-resistance, long life time 4-6 monthes, corrosion resistant, splicing technology, not easy to replace.

Washing Trommel Scrubber Linning Plate

In order to increase the washing effect, we always put linning plates insider of the drum scrubber part, it can be made below two kinds material:
1. Iron material spiral plates: normal material, can't be replaceable, welded inside drum.
2. Natual Rubber lined plates: wear-resistance, long life time, corrosion resistant, fixed with screw, replacable, easy to replace.

Rotary Scrubber Washer Main structure

1. Drum scrubber : For washing the clay.
2. Trommel scrubber Inner plate: separating the clay and ores, washing more clean the clay.
3. Trommel scrubber Sieving screen: for sieving different sizes ores, the screen mesh size& layer quantity & screen materials can be made according to customer need.
4. Diamond washing trommel scrubber Motor: electric or diesel according to your needs.
5. Carrier rollers: For support the drum
6. Gear, Reduction Box, coupling.
7. Machine Frame: Supporting the reduction box and motor.

Trommel Scrubber Washing Machine Technical Parameters
Model
Screen Size (MM)
Rotation Speed(R/Min)
Feeding size (mm)
Angle of inclination (degree)
Capacity (T/H)
Power (KW)
JXSC-400
≤20
27.9
≤80
≤10
1-5
3
JXSC-600
≤25
27.6
≤80
≤10
5-10
5
JXSC-750
≤25
27.6
≤100
≤10
10-30
7.5
JXSC-900
≤25
27.6
≤100
≤10
30-50
11
JXSC-1200
≤25
17
≤160
≤10
50-70
15
JXSC-1500
≤50
16
≤230
≤10
70-100
30
JXSC-1800
≤50
16
≤230
≤10
100-150
37
JXSC-2100
≤50
16
≤230
≤10
150-180
45

Trommel Scrubber Washing Machine Application

Trommel Scrubber Washing Machine is suitable to wash and sieve all kinds of material that with sticky clay, such as alluvial gold / tin ore/ tungsten ore/ chrome ore/ coltan ore/ beach sand/ zircon sand/ diamond/iron sand/manganese ore/silica sand/ kaolin clay/ gravel stone,ect.

JXSC PU Screen Trommel Scrubber Washing Machine 100TPH Gold Plant in Ghana

We designed flowchart based on customer's gold mine site details.

We supplied full set gold plant: vibrating feeder, trommel scrubber washing machine, gold centrifugal concentrator, sluice box and shaking table.

JXSC Trommel Scrubber Washing Machine installation in Nigeria customer's mine site

This Project is 50tph placer gold mining in Nigeria. We supplied hopper, feeder, trommel scrubber, gold centrifugal concentrator and sluice box.

JXSC Trommel Scrubber Washing Machine full set plant mining project in Angola.

We supplied full set plant includes hopper, feeder, trommel scrubber machine, vibrating screen and conveyor etc.

We sent our chief engineer Mr. Lee to guide at customer's mine site.

Packing & Shipping

Gold Trommel Scrubber Packing/Loading

1. Trommel Scrubber spare parts would be packed in wooden boxes to avoid broken.

2. Trommel Scrubber are fixed and loaded in container directly.






Gold Trommel Scrubber Machine Shipping

1. Trommel Scrubber are shipped in Flat Containers by sea.

2. Trommel Scrubber can be also shipped by air if customers request.

Related Products

Gold Wash Trommel Plant

100% response rate

Gold Centrifugal Concentrator

100% response rate

Gold Shaking Table

100% response rate

Separate Machine Jig Separator

100% response rate

Ball Mill Machine

100% response rate

Flotation Separator Machine

100% response rate

Crusher Station Crushing Plant

100% response rate

Multi-cylinder Hydraulic Rock Stone Cone Crusher Price

100% response rate

Jaw Crusher Stone Crushing Machine for Sale

100% response rate

Our company

Jiangxi Shicheng Mine Machinery Factory

Jiangxi Shicheng Mine Machinery Factory is an experienced supplier of complete set mining equipments, professional at providing complete set processing equipments for Gold ore /Tin ore /Tungsten ore /Iron ore / Diamond/ Coltan ore / Silica sand / Zircon sand/ Black sand/Chrome ore, ect. As well as complete set small lab mining machines.


Our Core Advantages as below :
1.+30 years history FACTORY at mining machinery
2.Provide engineer team after sales service
3.Provide Complete set mineral processing plant
4.Provide Sample testing service in factory lab for free
5.Provide professional Mining Solution Consulting

JXSC Main product including: trommel screen, trommel scrubber, shaking table, spiral chute separator, jig machine, centrifugal concentrator, sluice box, vibration screen, melting furnace, jaw crusher, hammer crusher, ball mill, flotation machine, spiral classifier. as well complete set small laboratory mining equipments

JXSC Mine Machinery Factory main markets

Africa, South Amercia, Europe , Southeast Asia, Asia,ect. Our cooperated customers cover Mali, Ghana, Sudan , Uganda, Mozambique, Suriname, Zambia, Nigeria, Cameroon, Madagascan, Malasia, Indonesia, Korea, Philippines, Monglia, Singapore, Inida, Iran, Mexico, Brazil, Chile, Peru, Spain, Canada, Austrilia,U.S, UAE,ect.

Our Service

Pre-Sales Service

*Inquiry and consulting support

*Ore sample testing support

*View our Factory

*Design Flowchart


After-Sales Service

* Training how to instal the machine, training how to use the machine.

* 1 year warranty
* Engineers available to service machinery overseas.

FAQ

1.How is the quality of your products? (mining equipment/machine)
Answer: Our products are manufactured strictly according to national and international standard, and we will take a test on every grinder before delivery.

2.Guaranteed?
Answer: All of our products are guaranteed for one year. If products quality is not consistent with the description as we described or the promise before you place order, we promise 100% refund.

3.How about price?
Answer: For the complete same machine, we can promise our quality is the best when the price same as other competitors, and our price can be lowest when the quality at standard level.

4.Service and Payment Terms?
Answer: We can accept T/T and L/C; 30% deposit, 70% balance before delivery, which is international trade practice; Finished product pictures will provide to customers before delivery.

Contacts

If you are interested in our products, please don't hesitate to contact us. You can tell me the following questions, so that we can send you accurate quotation soon, including extra discounts!

1. Which machine do you need? Like trommel scrubber, flotation machine, ball mill, magnetic separator, spiral chute, jig separator, shaking table, centrifugal concentrator, vibrating screen, vibrating feeder, etc.

2. What is your raw material plan to process? Like gold, diamond, tin, tintanium, tungsten, tantalite, manganese, coltan, zircon, rutile, monazite, copper or iron ore, etc.

3. The capacity you need? Like 100 tons per hour or 2000 tons per day.

4. Your contact information? Both email and phone number are essential, so that we can contact you easier.
