MB-2 is a specialized multi-function peripheral for bank front offices.
With its ultra-compact dimensions and extensive range of functions, MB-2 simplifies front-office installations and supports new applications.
MB-2 is the ideal tool for document platform solutions, enabling text and image acquisition directly by the cashier.
Functions such as optical character recognition and magnetic code line recognition, are just two of the many options available.
MB-2 is compatible with the applications currently implemented on the PR2, Olivetti’s highly successful bank printer.
A4 duplex scanner, black/white, greyscale and colors up to 600 dpi.
E13b and cmc7 magnetic code line reader.
24-dot matrix printer with auto-border and auto-alignment.
Three-port USB 2.0 hub, including a front-facing port, operator display for machine messages and application messages.
24-pin dot matrix
240 x 360 dpi
OCR A-B, Roman, Sans Serif, Italic, Courier
10, 12, 15, 16.6, 17,1 cpi
Printing speed at 10 cpi
VHSD: 560 cps NLQ: 185 cps
HSD: 510 cps LQ: 125 cps
Draft: 370 cps BIM: 2000 dps
238,76 mm (94 columns at 10 cpi)
1/5", 1/6", n/216", n/240"
Contact image sensor, flat bed
600 / 300 / 200 dpi
One pass, front and rear
RGB 24 bit / 256 grays / 16 grays / BW
Multiple windows selections (up to 9)
Recognized fonts: CMC7, E13B
Speed: >30cps (CMC7) or >18cps (E13B)
Type: USB 2.0
Ports: 1 frontal and 2 rear
Standard: RS232 serial, IEEE 1284 parallel and USB 2.0
< 54 dBA (ISO 7779 printing ECMA 132 text)
Original + 6 copies
Olivetti Standard, IBM PP & X24
Optional: WINCOR 4915
- Feed width: 245 mm
- Completely flat paper bed
- Automatic insertion with auto border
- Automatic document-thickness adaptation
4 million or 10 million characters
Max 10 inch/s (greyscale)
Full colors 3.3 inch/s
Image width up to 210 mm
Width: 65/245 mm
Length: 70/330 mm
Thickness: 0.08/1.8 mm
Unembossed credit and ID cards
Min. 6,8 W
Max. 85 W (printing)
230V / 50Hz
115V / 60Hz
Certifications & Regulatory
CE, TüV NRTL,FCC class A verified
384 x 296 x 204 mm
15.12" x 11.65" x 8.03"
