Multiple Effect Vacuum Flash Evaporator for Organic Wastewater Treatment Three Effect

FOB Reference Price:Get Latest Price
$1,000.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
ZONBO
Model Number:
Evaporator
Voltage:
Customized
Application:
Food Processing
Weight:
Customized
Certification:
CE ISO
Power Source:
Steam
Process:
Evaporation
Dimension(L*W*H):
Customized
Power(W):
Customized
Material 1:
Stainless Steel 304/316L
Material 2:
Carbon steel
Material 3:
Titanium
Outside surface:
Matt polish
Inside surface:
Mirror polish
Name:
forced circulation evaporator
feeding 3:
the material that temperature sensitive
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
18 Months
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plastic film and cotton cloth and wooden cases.
Port
Ningbo,Shanghai
Lead Time :
Shipped in 30 days after deposit payment

Description :

It is suitable for food, pharmaceutical, chemical, biological engineering, environmental engineering, waste recycling and other sectors of high concentration, high viscosity, also with insoluble solids to  low concentration.The evaporation system can widely used in the concentration of the glucose, starch sugar, maltose, milk, juice, vitamin C, maltodextrin and other aqueous solution. And also widely used in liquid waste disposal such as industry field of gourmet powder, alcohol and fishmeal.



Advantage:

Its outstanding advantage is its continuous operation and low temperature evaporation. It saves energy and time with low loss and maximize remain the material's color, fragrance and favor. It can satisfy the continuous production requirements. This product is mainly used in the industries such as food, Chinese and Western pharmaceutical, biochemical pharmaceutical, further processing of agricultural and auxiliary products, health drinks, juice, fine chemical, light industry, PRO-environment etc.



Structure:

Multiple-effect falling film evaporator consists of (first-effect, second-effect, third-effect)separators and evaporators and pre-heaters,condenser and vacuum pump, feeding pump,circulation pump, discharge pump, condensed water pump, pipeline and fittings, etc. It is equipped with CIP spraying cleaning ball, vacuum gauge, thermometer,pressure gauge,and so on.



Features:

1. It can be also used together with the coercive circulation evaporator and crystallizer to deal with the concentration and product crystallization of high viscous and easy scaled material.

2. It is characterized by high efficiency of heat conduction, low power consumption etc.

3. It can widely use the waster heat (such as the drier's hot air and flue gas), the remaining heat (of condensing water, process water and flash steam) to form a waste heat evaporation machine unit.



Characteristic:

1.Material: Stainless steel 304 or Stainless steel 316L.

2.Evaporation capacity: From 500Kg/h to 80T/h.

3.Full closed process, fast and low temperature evaporation.

4.Low steam consumption: 1kg steam can evaporate 3.5-4 kg water.

5.Inside pipes are mirror polishing seamless sanitary pipes, so material is not easy to paste on the pipe. It's easy for cleaning.

6.Large concentration ratio: adopt falling film evaporation, which make the material liquid with larger viscosity be easy to flow and evaporate, hard to scale,  short concentration time, the concentration ratio can reach to 1:5.

7.Low evaporation temperature:part of secondary steam can be inhaled into single-effect heater through spray type hot pressure pump. This would make full use of the heat and the evaporation temperature is low.

8.Can be designed into different technological process according to the different characteristics of the materials and different users' requirements.

9.This equipment  can realize automatic production, intellectual system management, which is in conformity with GMP standard.



Technical parameters:



FE500

FE1000

FE1500

FE2000

FE3000

FE5000

FE6000

FE8000

Evaporating capacity(kg/h)

500

1000

1500

2000

3000

5000

6000

8000

Steam pressure

0.1-0.25















(Mpa)

















Steam cost(kg/h)

185

370

555

740

1110

1850

2220

2960

Recycling water cost(t/h)

5

10

13

15

18

25

30

40

Weight(kg)

2060

2480

3280

4200

4860

5770

6430

7600

Dimension(mm)

7080*

7680*

8380*

8890*

9500*

10200*

10800*

11500*

900*

1000*

1100*

1200*

1300*

1400*

1500*

1600*

3500

4000

4600

4600

4900

5300

5800

5800

















Vacuum degree(MPA)

Evaporation temperature()

First effect

-0.047~-0.052

80-85

Second effect

-0.069~-0.072

70-75

Third effect

-0.075~-0.081

45-52




Welcome to visit our factory,which is 20 minutes driving from Wenzhou airport to our factory.
