New Product Uhf Rfid Reader Portal Long Range

Feedback Ratings
  • 1-9 Pieces
    $158.00
  • 10-99 Pieces
    $149.00
  • 100-999 Pieces
    $144.00
  • >=1000 Pieces
    $139.00
Model Number:
SR-RU120
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 500 Pieces)
Customized packaging (Min. Order: 500 Pieces)

More

Graphic customization (Min. Order: 500 Pieces) Less
Contact Supplier
Samples - $135.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Syncotek
Interface:
RS232, RS485, Weigand,Trigger,TCP/IP, UDP, WiFi
Name:
uhf rfid portal reader
Read Distance:
10m
Antenna:
9dbi
Read Speed:
100tags/s
RFID Protocol:
UHF ISO18000-6B/C
SDK:
Windows, Linux
Keyword:
rfid reader portal
Output Power:
30dbm(adjustable)
Power Supply:
+12V DC

Packaging & Delivery

Selling Units:
Single item
Single package size:
50X50X20 cm
Single gross weight:
5.0 kg
Package Type:
carton
Lead Time :
Quantity(Piece) 1 - 1 2 - 100 101 - 1000 >1000
Est. Time(days) 7 12 20 To be negotiated

Long Reading Distance 20m RFID Reader Writer UHF RFID Reader

Product Description

What is the overview of Wiegand TCP/IP 5 Meter Long Range Contactless 8dBi Antenna UHF RFID Writer Reader?

   SR-RU120 is a high performance UHF RFID integrated reader. It is designed with low power dissipation and high integrated RFID chip solution, which has features of long reading distance, high identification speed, multiple interfaces and easy installation. It can be widely applied in many RFID application systems such as logistics, access control, and anti-counterfeit and industrial production process control system etc.



What are the key features of Wiegand TCP/IP 5 Meter Long Range Contactless 8dBi Antenna UHF RFID Writer Reader?

*Adopt low power dissipation, high performance, long distance RFID module design;
*Support EPC global Class1 Gen2/ISO 18000-6C protocol tag;
*840~868MHz/902~928MHz frequency band (frequency customization optional);
*FHSS or Fix Frequency transmission;
*RF output power up to 30dBm (1dbm step adjustable);
*Built-in 8 dbi circular polarized antenna, effective distance over 10m;
*Support command, Auto and trigger working mode;
*Low power dissipation with single +12V DC power supply;
*Support RS232, RS485, Wiegand and Trigger interfaces;
*RJ45 (TCP/IP, UDP) and WIFI interface are optional, PoE optional;
*Support EPC, TID and USER inventory in independently or conjunctively;
*Support IAP firmware upgrading;

*Relay optional;
*Support IE Browser parameter configuration;
*Provide Windows & Linux demo software and SDK for testing and furtherly development.

What is the technical specification of Wiegand TCP/IP 5 Meter Long Range Contactless 8dBi Antenna UHF RFID Writer Reader?

Wiegand TCP/IP 5 Meter Long Range Contactless 8dBi Antenna UHF RFID Writer Reader

SR-RU120

Main Function
ProtocolEPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
Support Tags

Normal RFID tags;

Temperature sensor;

Moisture sensor rfid tag

RSSI TestingSupport
RFID
FrequencyEU 840~868MHz/ US 902~928MHz or customized
Fixed or FHSS
RF Power30dBm±1dB(Max)
Step Power1dBm
Channel Occupied
Bandwidth
<250KHz
AntennaBuilt-in 8dBi circular polarized antenna
Tag Reading
Effective Distance

8dBi circular polarized antenna, 30dBm, standard testing tag

Read:10m

Write:4m

Reading Speed

100tags/s

Communication Parameter
InterfaceRS232, RS485, Weigand 26/34 and Trigger
RJ45 and WIFI are optional
Baud Rate115200bps
Power Parameter
Operating Voltage+12.0V
Operating Current≤0.7A
Standby Current≤100mA
Temperature Parameter
Operating Temperature-20~+55°C
Storage Temperature-30~+85°C
Operating Humidity<95%RH (+25°C) Non-condensing

What is the technical specification of Wiegand TCP/IP 5 Meter Long Range Contactless 8dBi Antenna UHF RFID Writer Reader?

Item

Comment

Red

+12V

Black

GND

Yellow

Wiegand DATA0

Blue

Wiegand DATA1

Purple

RS485 R+

Orange

RS485 R-

Brown

GND

White

RS232 RXD

Green

RS232 TXD

Grey

Trigger input(TTL level)

More Pictures





Packaging & Shipping
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 3-7 days for samples; 5-25 days for batch goods.
Trade Terms

1. Payment: T/T, Western Union, MoneyGram, PayPal, D/A, D/P.
2. MOQ: 1pcs
3. Warranty : 1 years

Our Services

    Our products have acquired CE, FCC certification and RoHS compliance and NCC, KCC, EK improvement via Taiwan, Korea companies. Our products are with stability, conformity, high performance and competitive price. SYNCO has super excellent and experienced R&D team and sales engineer team which are the guarantee to provide our clients with superior products and service as well as OEM/ODM business.

We expect to cooperate with system integrators, strategic partners and product distributors.



Company information



Application


company ability

About Us


Established in 2004, SHENZHEN SYNCO TECHNOLOGY CO., LTD is a professional Hardware Solution provider of RFID solution ( RFID reader,RFID module, RFID tags, RFID antenna ) with Free Demo and SDK on Windows, Linux, android platform; card readers and special printers.

Our Advantages

WHY CHOOSE US

Global leading supplier

As a leading RFID UHF solution provider for warehouse, logistics, inventory checking, vehicle / asset / person Management, we have been dedicated to our field more than 12 years.

Wide range of rfid solutions

includes UHF RFID reader module, UHF integrated RFID reader, UHF fixed RFID reader, UHF antennas

RFID tags for different application





  • Related Products

    1 / 4 port rfid uhf module

    integrated uhf rfid reader

    r2000 uhf rfid fixed reader







Certifications

OUR CERTIFICATES



FAQ
Q

How can I get the sample to check your quality?

A

After price confirmation, you can require for samples to check our product’s quality. If you just need a blank sample to check the design and quality. We will provide you sample for free as long as you afford the express freight.

Q

What can I get the price?

A

We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please tell us in your email so that we will regard you inquiry priority.

Q

What is your term of delivery?

A

We accept EXW, FOB Shenzhen or FOB Guangzhou. You can choosethe one which is the most convenient or cost effective for you.


Q

What about the lead time for the mass production?

A

Honestly, it depends on the order quantity and the season you place the order.

Packaging & Shipping

Shipping

INTERNATIONAL AIR MAIL

Payment

Fast Delivery

Different amount of time will be required for different
Contact Us

How to find us?

Leo liang
Email: sales@ syncotek.com
Whatspp / wechat: +86 138 25290723
Skype:jokerwin

Web: http://www.syncotek.com

http://syncotek.en.alibaba.com
