OIML Approved Single Point Load Cell 3kg 6kg 10kg 15kg 20kg 30kg 40 kg 50kg for Price Computing Scales

FOB Reference Price:Get Latest Price
$6.00 - $10.00 / Piece | 10 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Customization:
Customized logo (Min. Order: 10 Pieces)
Customized packaging (Min. Order: 10 Pieces)

More

Graphic customization (Min. Order: 10 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
LCT
Model Number:
LAB-B3
Usage:
PRESSURE SENSOR
Theory:
Resistance Sensor
Output:
Analog SENSOR
Product name:
OIML Approved Single Point Load Cell
Application:
Mainly used for price computing scales,counting scales ect.
Material:
Aluminium Alloy
Capacity:
3,6,10,15,20,30,40,50(kg)
Rated output:
2.0±10%mv/V
Zero balance:
±5%R.O.
Linearity Error:
±0.015%R.O.
Max.platform size:
250*350mm
Protection Class:
IP65
Certificate:
OIMLR60, C3-C5
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
cartons,by sea/air
Port
Xiamen
Video Description

OIML Approved Single Point Load Cell 3kg 6kg 10kg 15kg 20kg 30kg 40 kg 50kg for Price Computing Scales

Product Description

Single Point Load Cells

 Capacity

 3,6,10,15,20,30,40,50(kg)

 Accuracy Class

 G*

 Rated output

 2.0±10%mv/V

 Zero balance

 ±5%R.O.

 Linearity Error

 ±0.015%R.O.

 Hysteresis/Repeatability Error

 ±0.01%R.O.

 Creep(30 minute)

 ±0.02%R.O.

 Structure

 Aluminium Alloy

 Temperature Compensated For Output

 ±0.02%R.O./10°C

 Temperature Compensated For Zero

 ±0.02%R.O./10°C

 Input resistance

 405±10Ω

 Output resistance

 350±3Ω

 Insulation Resistance

 ≥5000MΩ(50VDC)

 Temperature Compensated

 -10-+40°C

 Operating Temperature Range

 -20-+60°C

 Excitation,recommended

 5~12VDC

 Excitation,maximum

 18VDC

 Safe overload

 150%.R.C

 Ultimate Overload

 200%.R.C

 Cable,and length

 φ4mm*0.4m

 Protection Class

 IP65

Feature:

1. Aluminum alloy;
2. High accuracy, OIML R60 approved;
3. Mainly used for price computing scales, counting scales, weighing scales etc;
4. Max.platform size:250*350mm.
