Original Huawei FTTH Equipment GPON/EPON OLT SmartAX MA5612

FOB Reference Price:Get Latest Price
$160.00 - $580.00 / Pieces | 1 Piece/Pieces Original Huawei FTTH Equipment GPON/EPON OLT SmartAX MA5612 (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Huawei
Model Number:
MA5612
Type:
SmartAX MA5612
Width:
19-inch
Dimensions (Height x Width x Depth):
442 mm * 245 mm *43.6 mm
E81A:
8*channels E1 Access Port
EIUC:
8-Port Ethernet access Board.
ASNB:
16-Port Voice Service Access Boar
power input:
AC/DC
Voice:
SIP/H.248
Uplink:
GE/GPON/EPON/10 GPON
Application:
FTTH FTTB FTTX Network
Supply Ability
Supply Ability:
200 Piece/Pieces per Week Original Huawei FTTH Equipment GPON/EPON OLT SmartAX MA5612
Packaging & Delivery
Packaging Details
Original Carton Package(Original Huawei FTTH Equipment GPON/EPON OLT SmartAX MA5612)
Port
Shanghai
Lead Time :
3-7 working days after payment

Original Huawei FTTH Equipment GPON/EPON OLT SmartAX MA5612

Product Description

 The SmartAX MA5612 (the MA5612 for short) is an industry-leading remote multi dwelling unit (MDU) launched by Huawei, which supports flexible configurations and provides broadband services on the Fiber To The Building (FTTB) network and leased line services on a passive optical network (PON). The MA5612 is a box-type device measuring 1-U high and 19-inch wide and providing two GPON or GE uplink ports, 8–24 channel LAN access (LAN:POTS = 1:N) and 8–16 channel E1 access. The MA5612 features a broad temperature range, low power consumption, mute design, high stability, environment-friendlily and energy conservation, and can be used on workbenches and installed in corridors and cabinets, meeting broadband and leased line service deployment of customers.















Technical Specifications

     1.1 Dimensions of the MA5612



TypeWidth x Depth x Height
MA5612 (without the mounting brackets)442 mm x 245 mm x 43.6 mm
MA5612 (with the 19-inch mounting
brackets)
482.6 mm x 245 mm x 43.6 mm



     1.2 Weight of the MA5612

ConfigurationWeight
Empty shelf3.7 kg
Full configuration (two ASNB boards, each
of which provides 16 POTS ports)
4.22 kg



     1.3 Environment parameters of the MA5612



Environment ParameterValue
Working environment temperature-40°C to +65°C
The device can start up at -25°C and run at
-40°C.
Working environment humidity5% RH to 95% RH
Atmospheric pressure70 kPa to 106 kPa



      1.4 Power parameters of the MA5612



ParameterSpecification
Power supply mode AC power supply (110 VAC or 220 VAC) + backup power
(12 VDC)
 DC power supply (-48 VDC)
Working voltage range AC power supply: 90 VAC to 264 VAC
 DC power supply: -38.4 VDC to -72 VDC
 Backup power:
– Batteries will be charged when the device is powered
by an AC power source. The charging voltage supported by a lead-acid battery ranges from 13.5 V to 13.8 V. The charging voltage supported by a Felithium battery ranges from 14.1 V to 14.8 V.
– If the AC power source is cut off, the device will be powered by batteries. The discharging voltage supported by a lead-acid battery ranges from 10.8 V to 13.5 V. The discharging voltage supported by a Felithium battery ranges from 10.8 V to 14.4 V.
Maximum input current AC power supply: 1 A
 DC power supply :2 A





Usage Scenario:





Our Services
Packaging & Shipping

1).The ability of supply: 200 Piece/Pieces per Week.

2).Trade terms:FOB,CIF,CFR,etc.

3).Sample availability:yes(not free).

4).Pakage information:carton pakage with huawei original package.

5).Lead time: Within 5 working days after receipt payment.
6).Shipment: Express, Air, Sea..

Company Information
Name:Shanghai Chucheng Information TechnologyCo.,Lt.

Address: Room 110,No.389 JinWan Road, ShangHai , China

Specializing in Telecommunication and information technology fields, is one hightech enterprise integrating research, development, producing, sales and service. Its main products cover

optical transmission and access, copper transmission and access, optical and copper conversion and optical amplification.

With many domestic telecom carriers as cooperate partner, the company is also establishing a longterm relations abroad,

expanding overseas market and exporting to Europe, America, Southeast Asia, Middle East and so on and wining a good

reputation among these customers. The company is constantly improving itself, and would provide better quality, service

to partners with a co-win.

In terms of optical transmission products: PDH optical transmitter and receiver, E+E transmitter and receiver, 1+1 dual ports

transmitter and receiver, optical modem, convertor.
