PAL lens 4mm 1MP CCTV outdoor IP67 POE bullet DS-2CD1001-I 1.0 MP CMOS hik OEM Better than Dahua IP Network camera

  • 1-2 Pieces
    $29.40
  • >=3 Pieces
    $28.40
Type:
IP Camera
Style:
Bullet Camera
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
OEM Neutral
Model Number:
NC-IB1001/pal/4mm
Sensor:
CMOS
Special Features:
EXIR
Technology:
NetWork
Lens:
4mm
Image Sensor:
1/3" Progressive CMOS
Feature:
IP67 Weatherproof
IR Distance:
up to 30m IR visibility
Megapixel:
1MP
Warranty:
2-Year
Power Supply:
DC12V & PoE
Color:
white

Packaging & Delivery

Selling Units:
Single item
Single package size:
16X11X11 cm
Single gross weight:
0.4 kg
Package Type:
carton
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 3 4 - 500 >500
Est. Time(days) 7 30 To be negotiated
Product Description
 Characteristics:
 1.0 MP CMOS Network Bullet Camera
  • 1/4" progressive scan CMOS
  •  Up to 1.0 megapixel
  •  2.8mm/4mm/6mm fixed focal lens
  •  Up to 30 m IR range
  •  Dual stream
  •  Digital WDR (Wide Dynamic Range)
  • 3D DNR (Digital Noise Reduction)
  • PoE (Power over Ethernet)
  •  IP67
  •  Mobile monitoring via Hik-Connect or iVMS-4500

Specification

Camera

Image Sensor

1/2.8" progressive scan CMOS

Min. Illumination

Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR

Shutter Speed

1/3 s to 1/100, 000 s, support slow shutter

Lens

2.8 mm @F2.0, horizontal field of view 105.8°, 4 mm @F2.2, horizontal field of view 83.6°

6 mm @F2.0, horizontal field of view 55°

Lens Mount

M12

Day &Night

IR cut filter with auto switch

3-Axis Adjustment (Bracket)

Pan: 0° to 360°, tilt: -90° to 90°, rotation: 0° to 360°

DNR (Digital Noise Reduction)

3D DNR

WDR (Wide Dynamic Range)

Digital WDR

Compression Standard



Video Compression

Main stream: H.264+/H.264

Sub stream: H.264/MJPEG

H.264 Type

Baseline profile/Main profile

Video Bit Rate

32 Kbps to 8 Mbps


Max. Resolution

1920 × 1080

Main Stream

Max. Frame Rate

50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720)

60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream

Max. Frame Rate

50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288, 320 × 240)

60Hz: 30fps @(704 × 480, 640 × 480, 352 × 240, 320 × 240)

Image Settings

Brightness, saturation, contrast, sharpness are adjustable via web browser or client software

Day/Night Switch

Support auto, scheduled

Others

Mirror, BLC (area configurable), region of interest (support 1 fixed region)

Network

Network Storage

NAS (NFS, SMB/CIFS)

Detections

Motion Detection

Alarms

Video tampering, network disconnected, IP address conflicted

Protocols

TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour

Standard

ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI

General Function

Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Interface



Communication Interface

1 RJ45 10M/100M self-adaptive Ethernet port

General

Operating Conditions

-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)

Power Supply

12 VDC ± 25%, PoE (802.3af)

Power Consumption

Max. 5 W/6.5 W (PoE)

Ingress Protection

IP67

IR Range

Up to 30 m

Dimensions

69.1 mm × 66 mm × 172.7 mm ( 2.7" × 2.6" × 6.8")

Weight

500 g (1.1 lb.)
