PLC control parking smart car parking lift parking system

  • 10 - 19 Pieces
    $2,800.00
  • 20 - 49 Pieces
    $2,500.00
  • >=50 Pieces
    $2,200.00
Height (mm):
Depends on project
Width (mm):
Depends on project
Parking lot:
Depends on project
Lead Time:
Quantity(Pieces) 1 - 200 >200
Est. Time(days) 60 Negotiable
Customization:
COLOR (Min. Order: 10 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
plc control autoparking
Model Number:
PSH
Type:
Parking Lift
Warranty:
1 Years
Loading Capacity:
2000kg/2500kg
Mode of drive:
Hydraulic/Motor
Size of car(L*W*H):
Sedan:5000mm*1850mm*1550mm SUV:5000mm*1850mm*2050mm
Weight of car:
2000kg
Lifting motor power:
4-11kw
Lifting speed:
8-20m/min
Sliding motor power:
0.2kw
Sliding speed:
7.5m/min
Safeguard devices:
Hydraulic whole protection and anti-fall frame Anti-fall frame
Malfunction indication:
Fault diagnosis by computer,liquid crystal display
Modes of operation:
LCD/IC card/Manual
Supply Ability
Supply Ability:
500 Piece/Pieces per Month Auto plc control autoparking
Packaging & Delivery
Packaging Details
Packing:Four step packing to make sure safe transport.
(1)Iron frame to fix equipment;
(2)All structures fixed on the frame by screws;
(3)All electric wires and motor are put into iron box;
(4)Iron frame and box will be covered by stretch film.
Port
Qing Dao
Lead Time :
Quantity(Pieces) 1 - 200 >200
Est. Time(days) 60 To be negotiated

PLC control parking smart car parking lift parking system

Product Description

Working Principle

The equipment is designed with multi-levels and multi-rows and each level is designed with a space as an exchanging space.All spaces can be lifted automatically except the spaces in the first level and all the spaces can slide automatically except the spaces in the top level.When a car needs to park or release,all spaces under this car space will slide to the empty space and forms a lifting channel under this space.In this case,the space will go up and down freely.When it reaches the ground,the car will go out and in easily.

Characteristics of the system

low area coverage and high usage rate of space.The levels and rows may be designed according to the customers'requirements;Outer packing types may be designed as full packing,half packing,simple packing or nude packing according to the customers' requirements;this type of packing system has low cost and low maintenance cost;It operates steadily without noise and with fast operating speed and short parking and releasing time;Multi-channels safety protection and series of safety protection and series of safety protection and series of safety protection devices for anti-fall,anti-crashing and anti-overloading.

Parameters

Mode of driveHydraulic
Size of car(L*W*H)

Sedan:5000mm*1850mm*1550mm

SUV:5000mm*1850mm*2050mm

Weight of car2000kg
Lifting motor power speed4-11kw     8-20m/min
Sliding motor power speed0.2kw      7.5m/min
Safeguard devices

Hydraulic whole protcction and anti-fall frame

Anti-fall frame

Malfunction indicationFault diagnosis by computer,liquid crystal display
Parts appearance treatment

Galvanized treatment and high-grade

Anti-corrosion paint

Modes of operationLCD/IC card/Manual



Pictures

4

VERTICAL-HORIZONTAL PSH2-15--2

4 level

4PSH







Packaging & Shipping

Packing:Four step packing to make sure safe transport.

                 (1)Iron frame to fix equipment;

                 (2)All structures fixed on the frame by screws;

                 (3)All electric wires and motor are put into iron box;

                 (4)Iron frame and box will be covered by stretch film.



packing2





Shipping:1)Export port:Qing Dao China

                   2)Shipping time:Within 60 days after receive deposit.

Our Services



Quality Commitment:  A.In one year warranty,  If there is loss because of  design or                                                   producing ,we will be responsible for it.

                                                          B.we guarantee our  equipments are new, not used.  produced                                                   from good material by first-class technic.



 Customer service:        I. Lifetime  Service (Total one year warranty for free, lifetime                                                    provide accessories);

                                                        II. Provide one set of spare parts for f

                                 III.Provide engineer to guide  installation work for free.

                                 IV.Provide technology consulting and  design for free





Company Information



Da Yang Parking CO.,LTD was established in 2001,  has over 14 years experience in parking equipments designing, manufacturing, installation and maintenance.



We adopted Japanese technology with an investment over CNY600, 000,000.00



                                                                      Pictures of our company



 .jpg

Our company has modern production workshops building area over 60000 square meters,

science and research office building area over 15000 square meters as well as lots of

advanced and super production equipment.

workshop





CERTIFICATE 2019.jpg





    Da Yang at  the  Fair

fair



More project cases

display case

18



"Space is limited and parking is unlimited"



Welcome all friends and partners from the world for a bright future!
