PU Flat Shape Silk Screen Printing Squeegee Rubber Blade

FOB Reference Price:Get Latest Price
$10.00 - $30.00 / Rolls | 1 Roll/Rolls (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
M&K100
Place of Origin:
Hebei, China
Brand Name:
M&K
Standard length:
4000mm
Width range:
50-500MM
Length range:
100-4000MM
Standard size:
50*9mm , 50*10mm,40mm*7
Application:
Silk Screen Printing
Material:
100% Polyurethane
Hardness:
45~95 SHORE A
Thickness rang:
2-30MM
standard:
straight square and customized edge
Standard color:
Brown,Red,Blue,Green,White,coffee
Supply Ability
Supply Ability:
8000 Meter/Meters per Day
Packaging & Delivery
Packaging Details
Packaging Details:in cartons ,1 roll/box ,10 rolls/carton
Port
TIANJIN PORT
Lead Time :
Shipped in 5 days after payment

Product Detail

Standard length4000MM
Width range50-500MM
Length range100-4000MM
Standard size50*9mm , 50*10mm, 40mm*7
ApplicationSilk Screen Printing
Material100% Polyurethane
Hardness45~95 SHORE A
Thickness rang2-30MM
standardstraight square and customized edge
Standard colorBrown,Red,Blue,Green,White,coffee
Product Keywordsscreen printing squeegee sharpener

Standard hardness



Soft        45-65 ShoreA   red or coffee        Suitable for the low mesh screen cloth,low viscosity ink,irregular



                                                                          surface of the printing



Medium  70-75 ShoreA   green or coffee   Suitable for various of mesh screen cloth,various of ink and various

                                                                     of the prints

Hard       80-85 ShoreA   blue or coffee



Super hard  90-95ShoreA   white         Suitable for high pressure,high viscosity ink,the fine print of the printing



Other hardness or colors are available on request.

Standard size:1MM--4000MM   Width:3--500MM   Thickness:1--20MM

Specifical size is available on request.

Mark:ink jet marking on blade quality size and hardness shoreA ect.



Product Description

screen printing squeegee sharpener

The hardness of the squeegee is devided into three categories

1.In generally speaking ,the soft squeegee suitable for the low mesh screen cloth,low viscosity ink,irregular surface of the printing.Using the soft squeegee for printing,large amount of ink,printing image fidelity is moderate,is usually used for large area printing,ceramics and glass.

2.The medium hardness squeegee is used for high pressure.Suitable for various of mesh screen cloth,various of ink and various of the prints use this kinds of squeegee the printing ink accumulate very well.Image resolution power is good,suitable for all kinds of printed substrates.

3. The hard squeegee used for the largest printing pressure and printing ink viscosity is very high.Small amount of oil accumulation and image resolution are usually in the screen printing can choose the hard squeegee.it produces the ink layer is very thin.



The maintenance storage of the squeegee

1.Shall be falt,don't placed into rolls

2.Shall be open the whole roll 24 hours make sure the squeegee complete stretch befor using.

3.Storage without removing the handle,the article blowing up,should be used when the stencil scraping the article can't contact with any object.

4.When store the squeegee,the temperature should be 20℃to 25℃ degrees and dry environment,away from the ink ,because the squeegee can absorb moisture in the air and solvents.

5.The squeegee with ink or handle can't stored overnight.

6.Do not put the squeegee in the solvent for long time.although the squeegee can be resistant to many kinds of solvents,but long time of soaking will make the squeegee deformation,loss of elasticity.

7.Shall be immediately flush after using it to avoid ink dry on the squeegee.After cleaning the rubber handle there won't have any residual ink marks,otherwise when using the squeegee next time will have mark.

8.Use the soft cloth to clean the squeegee,along the direction of the squeegee to clean.otherwise reverse cleaning will damage the squeegee edge.

Abpve all it is very important to the select and use the squeegee.in the midst of our printing,undertake choosing according to various substrates with different squeegee.it will have great effect for silk screen printing quality.







Application


Application

The squeegee is widely used in screen printing on textile, decoration, uneven and rough surfaces. It performs well in medium pressure, low counts mesh, and low viscosity ink.

  • The best solvent resistance, multi-color printing.

  • Te highest wear rub electronic printed circuit boards

  • Excellent weather resistance  (temperature, humidity) Container Printing (bottles, cans).

  • Easy to grind automatic textile printing.

  • Individually packaged to prevent light and dust, fingerprints or other machine printed
