Plastic splitter 1x8 plc sc apc 1x 2 2x2 fiber splice tray patch panelplc splitter module,PLC optical fiber spplitter

FOB Reference Price:Get Latest Price
$3.99 - $19.99 / Piece | 100 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Lead Time:
Quantity(Pieces) 1 - 10 11 - 100 >100
Est. Time(days) 1 1 Negotiable
Customization:
Customized logo (Min. Order: 10000 Pieces)
Customized packaging (Min. Order: 10000 Pieces)
Samples:
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
For ODF Box
Model Number:
Inserting fiber optic splitter
Package details:
46 X 33 X 23 CM:(100PCS)
Durability:
>1000
OEM:
Support
Mode:
Inserting disk
Jacket:
OFNR flame retardant
Product Type:
PLC fiber optic splitter
Application:
CWDM System/PON Networks/CATV Links .
Connector:
SC APC UPC
port:
1x2,2x2,1x8,1x16
Fiber Material:
ABS,Plastic
Supply Ability
Supply Ability:
100 Piece/Pieces per Day Plastic splitter 1x8 plc sc apc PLC optical fiber spplitter
Packaging & Delivery
Packaging Details
Plastic splitter 1x8 plc sc apc 1x 2 2x2 fiber splice tray patch panelplc splitter module,PLC optical fiber spplitter
1.packing size : 47*33*30cm
2.1PCS/tray
3.100pcs/carton
4. WG/carton: 6KG
Port
Shenzhen port or Hongkong port
Lead Time :
Quantity(Pieces) 1 - 10 11 - 100 >100
Est. Time(days) 1 1 To be negotiated

Plastic splitter 1x8 plc sc apc 1x 2 2x2 fiber splice tray patch panelplc splitter module,PLC optical fiber spplitter





Contact us.

 Qingying is a manufacturer specializing in optical passive components , main products have Optical Fiber Fast Connector , Adapter , Pigtal , Attenuator , Ceramic Sleeve , Patch Cord , SFP Case , PLC Splitter , PLC Steel Pipe , MPO , Waterproof connector and Metal Processing.





Product Pictures



1X2 SC 20170304_111135

 DSC_3693123 020





The fiber optic splitter is one of the most important passive devices in the optical fiber link, is optical fiber tandem device with many input terminals and many output terminals, especially applicable to a passive optical network (EPON.GPON.BPON.FTTX.FTTH etc.) to connect the MDF and the terminal equipment and to achieve the branching of the optical signal.



Ports

1×2

1×4

1×8

1×16

1×32

1×64

Operating Wavelength (nm)

1260~1650

Insertion Loss (dB)

Max(P/S)

3.8/4.0

7.1/7.3

10.2/10.5

13.5/13.7

16.5/16.8

20.5/21.0

Loss Uniformity (dB)

Max

0.6

0.6

0.8

1.2

1.5

2.5

PDL (dB)

Max

0.15

0.15

0.25

0.3

0.3

0.3

Return Loss (dB)

Min

UPC:50   APC:55

Directivity (dB)

Min

55

Standard Input Fiber

Bend Insensitive SM Single Fiber(ITU G.657A)

Standard Output Fiber

Bend Insensitive SM Ribbon Fiber(ITU G.657A)

Standard Output Color

Blue, Orange, Green, Brown, Grey, White, Red ,Black(TIA/EIA 598-B)

Max. Optical Power(mw)

300

Humidity Range(rh)

5%~85%

Operating Temperature(

-40~+85

Storage Temperature(

-40~+85

Connector Options

FC/SC/LC/ST/MU

Packaging Options

Bare Device*Mini Tube*ABS Module*LGX Box*19''/23'' Rack-mount

*Telcordia GR-1221-CORE&G-1209-CORE Compliant.
*Premium spec available upon request. (P/S: Premium Grade/Standard Grade)
*Typical value at +23 without connectors losses.





Factory Scale:

Total Area of: 8000 square meters

Factory history: 10 years

Production Staff: 60 to 100
QC Staff:
10 to 12
R&D Staff:
5 to 10

Certificates:

ISO9001:2015

SGS

RoHS

CE

Logistics Ability:

Arrange the Mixed logistical for Election delivery as By Air and By Sea,

over 10 years’ experience for logistical arrange.

Features;

Good uniformity and low insertion loss

 Low Polarization Dependent Loss

Excellent Environmental Stability

Excellent Mechanical

Stability

Delivery Time:

Material Preparation Time: 3 days (or inventory)

Production & Assembly Time 7 days

Testing & Packaging Time: 2 days

Total Delivery Time:  15 days in 15000pcs

 for safe delivery lead time.

The faster delivery could be negotiable.

Applications:

1.Asynchronous Transmission Mode(ATM)     Package for 100PCS   :

2.Passive optical networks (PON)

3.Fiber to The Home (FTTH)                          Package dimensions :47 X 33 X 30 CM

4.Local Area Networks (LAN)

5.Cable Television (CATV)

6.Test Equipment



 PLC



Related Products









Company Information





 _061684_08750



Packaging & Shipping

paste-pic-dp_uuid_bypeu





FAQ



1. How do you guarantee the quality?


Before the production, we would make pre-production to confirm with customers. During the production, we have professional QC to inspect the products while manufacturing. And we also warmly welcome customer's QC to inspect the goods before shipment.


2. Can you factory pass the factory audit?


Yes, our factory passed the ISO 9001:2015 certification TUV,ROSH.


3. What's the Products leadtime?


Our sample leadtime is 1 days, and bulk production time is 15-35 days when we receive the deposit and confirm the pre-production sample with customer.


4. Can I have my own logo on the products ?


Yes, we warmly welcome your own logo, the logo can stamp, laser and engrave, etc.


5. What's your payment term?


Our payment term is 30% deposit, 70% balance before shipment.


6. Do you offer any other goods?


Our factory mainly offer fast connector,adapter, attenuator,plc splitter,plc pipe,patch cord, pigtail, ceramic sleeve etc.
