Platinized titanium mesh anode

FOB Reference Price:Get Latest Price
$25.80 - $32.50 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shaanxi, China
Brand Name:
CSTI
Model Number:
CS-Ti-Anode
Application:
Industry
Technique:
Acid washing,Brush coating
Dimensions:
Customized
Grade:
Gr1 Ti as substrate
Powder Or Not:
Not Powder
Ti Content (%):
99.6%
Shape:
Mesh, Plate, Basket, Rod, Tubular
Coating:
RuO2 / RuO2-IrO2
Role:
conducting material
Current Density:
3500A/M2
Working Temperature:
80-85 C
Substrate:
Gr1 titanium
Coating Content:
10-20 g/m2
Supply Ability
Supply Ability:
33000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Plastic or paper as inside,carton or plywood case as outside,or as clients' demands
Port
Shanghai
Lead Time :
5-20days



Platinized Titanium Anode (Mesh)

  • Base Material: Titanium (Gr1, Gr2, TA1, TA2)
  • Shape: Mesh (customized)
  • Working Current: < 8000 A/m2
  • Workmanship: Plating
  • Coating Material: Platinum (purity 99.99%)
  • Noble Metal Content: ≥ 21.48  g/m2
  • Platinum Thickness:  0.2-15μm
  • Temperature:  < 80℃
  • PH Value: 1-12

Properties:  application-specific design, tight adhesion between platinum layer and base titanium material, stable performance, high current and low voltage, even coating.

Application: seawater, gold potassium cyanide + citric acid, horizontal plating, pulse plating, athode protection. It can be used in acidic or alkaline electroplating solution.

Technique :  Sand blasting ; Annealing ; Straightening ; Acid Washing ; Brush Plating ; Sintering





More About Titanium Anodes

Substrate

Titanium Plate and mesh

About Plate

Plate Grade/Purity

Gr1/Gr2 Pure titanium plate,more than 99.6% purity.ASTM B265

Plate Chemical composition

Grades

N

C

H

Fe

O

Ti

Gr1

0.03

0.08

0.015

0.20

0.18

bal

Gr2

0.03

0.05

0.015

0.30

0.25

bal

Substrate

Mechanical properties

Grades

Tensile strength (min) MPa

Yield strength  (min) MPa

Elongation

(%)

Gr1

240

138

24

Gr2

345

275

20

About Mesh

Mesh Grade/Purity

Gr1/Gr2 Pure titanium mesh,more than 99.6% purity.ASTM B265

Regular Mesh Cell

3*6mm/4*8mm/5*10mm/4.5*12.5mm

Mesh Stem

More than 1mm

Regular Coating

Platinum:0.5um/1um

Mixed Iridium and Platinum:0.5um/1um

Mixed Ruthenium and Iridium:6-8um

Mixed Iridium and Tantalum:6-8um

Characteristics

Coating: Mixed Ruthenium and Iridium

Chlorine evolution potential: <1.13V

Polarizability: ≤40mv

Accelerated life:   ≥3000min under current density 1000A/m2

Anode strengthening weightlessness: ≤10mg

Suitable working environment: Solution contains Cl-, PH<=7

Coating contents and life span

8 grams/m2:  >6,000  hours

10 grams/m2:  > 8,000 hours

12 grams/m2:  >10,000 hours

15 grams/m2:  >12,000 hours

20 grams/m2:  >15,000 hours

Working parameters

Current density: <600A/m2

Temperature: 40-60°C

Chlorine concentration: About 30~50grams/liter

Polarity reversal: suitable

Reversal frequency: 2-4 hours

Regular sizes

63.5*150mm, 13 pcs one unit

64*110mm, 7 pcs one unit

80*120mm, Single piece

30*183mm, 7pcs one unit

80*185mm, 7pcs one unit

Applications

Electroplating Industries

a. Electro dialysis  b. Electrolytic cells

c. Sensing elements   d. Waste water treatment

e.Precious metal recovery  f. Rotogravure printing

Cathodic Protection Applications

a. Sea water intakes  b. Heat exchanger & Condensers

c. Jetties & Tanks  d. Water heaters



Anode Photos Details Show;

Titanium electrode (anode and cathode)

The electrode is made from a base and a coating.

Among many materials tested, the choice of the support, or substrate as you say in scientific language, has fallen on Titanium.Titanium has in fact the features required in order to receive the coating, to resist the chemically aggressive environments of the processes and it’s suitable for the current’s conduction.Another advantage of Titanium is that it can be worked in a wide range of shapes: sheets, nets, tubes, wires, complex manufactured products etc.The electrode was born from the combination of coating and Titanium, which has afterwards taken different commercial names: DSE - DSA - MMO etc...



The coating

It’s a very thin layer, a few microns, which covers the titanium’s surface in the areas where the anodic reaction takes place.

It’s composed by oxides, in variable percentages, of noble metals belonging to the Platinum family.In particular Ruthenium and Iridium are the main elements used, mixed with others within the same family: Palladium, Rhodium, Platinum.The formation of the coating takes place through the application of a solution of the above described salts’ elements and a subsequent high temperature thermal treatment to create the oxide.Each application or “coat” is a cycle during which a fraction of the prearranged coating’s quantity settles. The number of cycles is subject to the final noble metal’s load, which, in turn, is in relation to the type of final use it’s designed for.There are many formulations or “recipes” for coating, each of which is specific for its final use.You can distinguish between two families: anode and cathode coating.Among the anode coatings you can distinguish between: coating for Chlorine evolution, coating for Oxygen evolutionor mixed coating.The key component or the “catalyst” of the coating for Chlorine evolution is Ruthenium Oxide; for Oxygen evolution it is Iridium Oxide.Membrane cell cathode coatings are based on Ruthenium Oxide or Platinum, mixed with Palladium, Rhodium.



Packages;



Work Flows;





Customers Coming;

Find Us Abroad Fair;
